John Bean EELR529A - Page 39

- 39 -
Jack Beam Installation, Operation and Maintenance Manual
Item #
CL Part #
Qty/Jack
Description
1
RJ9-04-00
2
Footpad
2
EAA0485V31A
1
Air/Oil Pump
3
VS10-31-08
4
M8 x 12 Flat Head Screw
4
RJ6-19
2
Stop Bar
5
RJ6-02CH
2
Arm
6
RJ7.5-01
1
Sleeve
7A
RJ7.5-07F
1
Outer Scissor Plate, Front
7B
RJ7.5-07R
1
Outer Scissor Plate, Rear
8
RJ6-06-04
1
Upper Pin Roller
9
RJ6-13
1
Upper Pin
10
VS10-20-10
6
5mm Roll Pin
10A
X10-099
4
20mm Washer
11
RJ6-18
2
Roller
12
RJ7.5-15A
2
Side Member Weld
13
RJ6-08
1
Main Pin
14
RJ6-23
2
Spacer Washer
15
RJ6-12
1
Upper Pin, Fixed End
16
RJ7.5-06
1
Internal Scissor
17
RJ7.5-11
1
Jack Body
18
RJ6-27CH
4
16mm Dia. Shoulder Bolt
19
RJ6-17CH
4
Wheel
20
RJ6-24CH
4
Nylon Washer
21
RJ6-26A
4
Compression Spring
22
RJ6-25CH
4
Carrier
23
RJ7.5-16
1
Lock
24
RJ7.5-20
1
Lock Pin
24A
RJ7.5-35
2
21mm Snap Ring
25
EAM0156V25A
2
Pump Hold Down Plate
27
1-17788A
2
SOCKET HEAD CAP SCREW GB/T70.1-2000
M6*20
28
1-22288A
2
M6 Nylon Locknut GR.8, GB/T889.1-2000
29
RJ6-09CHA
1
Cylinder, Flow-Restricted
30
RJ7.5-15-00
2
Side Member Assembly
31
X10-077
4
M10 x 25 HHCS
31A
RJ6-38
4
M10 Hex Nut
32
RJ6-05
4
3" Stack Pad
33
RJ6-14
1
Cylinder Pin
33A
RJ6-40
2
15mm Snap Ring
34
RJ6-22CH
1
Hydraulic Elbow
35
RJ6-21CH
1
Hydraulic Hose
36
RJ6-31
2
10mm Push Lock Elbow
37
1-04488A
2
Flat washer Φ6 GB/T 95-2002
38
JSJ3-10-04
1
3/8 NPT x 14mm 37 Deg. Flare
40
Z16777
1
Jack Capacity Decal
IMPORTANT!
Replace all worn, damaged, or broken parts with parts approved by Snap-on Equipment.
Contact 1-800-225-5786
