JOHNSON CONTROLS
10
FORM 100.50-SU8
ISSUE DATE: 1/28/2016
SECTION 2 - CONNECTING BAS TO A SERIES 100/YPAL UNIT WITH THE IPU CONTROLLER
IPU Board
SW2: MAC Address Switch
SD Card Slot
Port 3 (J2)
Port 1 (J4) BACnet MS/TP
MUST connect here
Port 4 (J3)Port 2 (J5)5 VDC Power
Battery
SW1: Not
Used
FIGURE 1 - IPU CONTROLLER PORT LOCATIONS
LD20051
