SECTION 12 - BACNET MS/TP POINTS
FORM 100.50-SU8
ISSUE DATE:1/28/2016
12
TABLE 2 - WARNING DESCRIPTION TABLE (CONT'D)
HISTORY
SCREEN
WORDING
DESCRIPTION RESET
SHOW WHEN
UNIT TYPE IS
STATUS
SCREEN
WORDING
FAULT
OUTPUT
TYPE
WRN-SLAB
TEMP
SENSOR
UDERFLOOR SLAB TEMP SENSOR
IS OUT OF RANGE FOR more than or
equal to10 SECONDS
AUTO
RESET
UNIT TYPE
IS FLEXSYS
AND DEW
POINT RESET
IS USER
ENABLED
SENSOR/
MISC
STATUS
WARNING
SENSOR/
MISC FAULT
WRN-
SUCTION PRS
SENSOR *
SUCTION PRESSURE OUT OF RANGE
FOR more than or equal to 10 SECONDS
AUTO
RESET
PRESS TRANS
PKG IS ON
FOR THE
SYSTEM
SENSOR/
MISC
STATUS
WARNING
SENSOR/
MISC FAULT
WRN-
SUCTION
TEMP
SENSOR * #
SUCTION TEMPERATURE SENSOR
IS OUT OF RANGE FOR more than or
equal to 10 SECONDS
AUTO
RESET
SENSOR/
MISC
STATUS
WARNING
SENSOR/
MISC FAULT
WRN-UNDER
FLOOR RH
SENSOR
UDERFLOOR AIR HUMIDITY IS less
than 5% FOR more than or equal to 5
MINUTES
AUTO
RESET
UNIT TYPE
IS FLEXSYS
AND DEW
POINT RESET
IS USER
ENABLED
SENSOR/
MISC
STATUS
WARNING
SENSOR/
MISC FAULT
* CAN BE 1, 2, OR 3 # CAN BE A OR B
