689670-BIM-A-0311
14 Johnson Controls Unitary Products
Figure 13: ZU-A3 thru -A5 Unit Left Duct Opening
Figure 14: ZU-A3 thru -A5 Roof Curb
4-5/16
30-3/8
8 or 14
50-1/2
30
20
20
80-5/8
6
2 TYP.
INSULATED DECK UNDER
COMPRESSOR SECTION
INSULATED DECK UNDER
CONDENSER SECTION
FRONT
RIGHT
SUPPLY
RETURN
