Table 8: Electrical Data
ZU-A3 thru -A5 Standard Indoor Blower - Without Powered Convenience Outlet
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
1. Minimum Circuit Ampacity.
MCA
1
w/Pwr
Exh
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
Max Fuse
2
/
Breaker
3
Size w/
Pwr Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
-A3
(3)
208 9.1 68 14.2 1.5 6.0 5.5 0.0
None---18.924.425 30
E03 2.3 1 6.4 18.9 24.4 25 30
E06 4.5 1 12.5 23.1 30 25 30
E08 6.8 1 18.9 31.1 38 35 40
E15 11.3 2 31.4 46.7 53.6 50 60
230 9.1 68 14.2 1.5 6.0 5.5 0.0
None---18.924.425 30
E03 3 1 7.2 18.9 24.4 25 30
E06 6 1 14.4 25.5 32.4 30 35
E08 9 1 21.7 34.6 41.4 35 45
E15 15 2 36.1 52.6 59.5 60 60
460 4.5 34 7 0.8 3.0 2.2 0.0
None - - - 9.4 11.6 15 15
E03 3 1 3.6 9.4 11.6 15 15
E06 6 1 7.2 12.8 15.5 15 20
E08 9 1 10.8 17.3 20 20 20
E15 15 2 18.0 26.3 29.1 30 30
575 3.8 28 6 0.6 2.4 1.8 0.0
None - - - 7.8 9.6 15 15
E08 9 1 8.7 13.8 16.1 15 20
E15 15 2 14.4 21 23.3 25 25
-A4
(4)
208 11.2 88 17.5 1.5 6.0 5.5 0.0
None---21.527 30 35
E06 4.5 1 12.5 23.1 30 30 35
E08 6.8 1 18.9 31.1 38 35 40
E15 11.3 2 31.4 46.7 53.6 50 60
E20 15 2 41.6 59.5 66.4 60 70
230 11.2 88 17.5 1.5 6.0 5.5 0.0
None---21.727 30 35
E06 6 1 14.4 25.5 32.4 30 35
E08 9 1 21.7 34.6 41.4 35 45
E15 15 2 36.1 52.6 59.5 60 60
E20 20 2 48.1 67.6 74.5 70 80
460 5.6 44 8.0 0.8 3.0 2.2 0.0
None---10.813 15 15
E06 6 1 7.2 12.8 15.5 15 20
E08 9 1 10.8 17.3 20 20 20
E15 15 2 18.0 26.3 29.1 30 30
E20 20 2 24.1 33.8 36.6 35 40
575 4.5 36 7.0 0.6 2.4 1.8 0.0
None - - - 8.6 10.4 15 15
E08 9 1 8.7 13.8 16.1 15 20
E15 15 2 14.4 21 23.3 25 25
E20 20 2 19.2 27.1 29.3 30 30
-A5
(5)
208 14.1 88 22 1.5 6.0 5.5 0.0
None---26.632.135 45
E06 4.5 1 12.5 26.6 32.1 35 45
E08 6.8 1 18.9 31.1 38 40 45
E15 11.3 2 31.4 46.7 53.6 50 60
E20 15 2 41.6 59.5 66.4 60 70
E23 18 2 50.0 70 76.8 70 80
230 14.1 88 22 1.5 6.0 5.5 0.0
None---26.632.135 45
E06 6 1 14.4 26.6 32.4 35 45
E08 9 1 21.7 34.6 41.4 40 45
E15 15 2 36.1 52.6 59.5 60 60
E20 20 2 48.1 67.6 74.5 70 80
E23 24 2 57.7 79.7 86.5 80 90
460 7.7 55 12 0.8 3.0 2.2 0.0
None---14.216.420 20
E06 6 1 7.2 14.2 16.4 20 20
E08 9 1 10.8 17.3 20 20 20
E15 15 2 18.0 26.3 29.1 30 30
E20 20 2 24.1 33.8 36.6 35 40
E23 24 2 28.9 39.8 42.6 40 45
575 5.1 36 7.5 0.6 2.4 1.8 0.0
None-- - 1011.815 15
E08 9 1 8.7 13.8 16.1 15 20
E15 15 2 14.4 21 23.3 25 25
E20 20 2 19.2 27.1 29.3 30 30
E23 24 2 23.1 31.9 34.1 35 35
