Johnson Controls 5 J ZE Series User Manual

5742639-JIM-C-0220
18 Johnson Controls Ducted Systems
J05
(5.0)
208-1-60
4
24.4 144.2 38 4.4 6.7 0
NONE - - - 41.6 50
E05 4 1 19.2 41.6 50
E07 5.6 1 26.9 42 60
E10 8 1 38.5 56.5 60
E15 11.9 2 57.2 79.9 80
E20 15.9 2 76.4 103.9 110
E30 22.2 2 106.7 141.8 150
230-1-60
4
24.4 144.2 38 4.4 6.7 0
NONE - - - 41.6 50
E05 5.3 1 22.1 41.6 50
E07 7.5 1 31.2 47.4 60
E10 10.6 1 44.2 63.6 70
E15 15.9 2 66.2 91.2 100
E20 21.2 2 88.3 118.8 125
E30 29.6 2 123.3 162.5 175
208-3-60 16 110 24.9 4.4 4.3 0
NONE - - - 28.7 35
E05 4 1 11.1 28.7 35
E07 5.6 1 15.5 28.7 35
E10 8 1 22.2 33.1 40
E15 11.9 2 33 46.7 50
E20 15.9 2 44.1 60.5 70
E30 22.2 2 61.6 82.4 90
230-3-60 16 110 24.9 4.4 4.3 0
NONE - - - 28.7 35
E05 5.3 1 12.7 28.7 35
E07 7.5 1 18 28.7 35
E10 10.6 1 25.5 37.2 40
E15 15.9 2 38.2 53.2 60
E20 21.2 2 51 69.1 70
E30 29.6 2 71.2 94.4 100
460-3-60 7.8 52 12.1 4.4 2.1 0
NONE - - - 14.1 20
E07 6.8 1 8.2 14.1 20
E10 10.1 1 12.1 17.8 20
E15 13.6 2 16.4 23.1 25
E20 19.5 2 23.5 31.9 35
E30 28.8 2 34.6 45.9 50
575-3-60 5.7 38.9 8.9 4.4 1.9 0
NONE - - - 10.8 15
E10 10.6 1 10.2 15.1 20
E15 15.9 2 15.3 21.5 25
E20 21.2 2 20.4 27.9 30
E30 30.4 2 29.3 38.9 40
JA6
(6.0)
208-3-60 19.6 136 27 4.4 4.3
None - - - 33.2 45
E05 4 1 11.1 33.2 45
E07 5.6 1 15.5 33.2 45
E10 8 1 22.2 33.2 45
E15 11.9 1 33 46.6 50
E20 15.9 2 44.1 60.5 70
E30 22.2 2 61.6 82.4 90
230-3-60 19.6 136 27 4.4 4.3
None - - - 33.2 45
E05 5.3 1 12.7 33.2 45
E07 7.5 1 18 33.2 45
E10 10.6 1 25.5 37.3 50
E15 15.9 1 38.2 53.1 60
E20 21.2 2 51 69.1 70
E30 29.6 2 71.2 94.4 100
460-3-60 9.4 66.1 13 2.4 2.1
None - - - 16.3 25
E07 6.8 1 8.2 16.3 25
E10 10.1 1 12.1 17.8 25
E15 13.6 1 16.4 23.1 25
E20 19.5 2 23.5 32 35
E30 28.8 2 34.6 45.9 50
575-3-60 7.1 55.3 10 4.4 1.9
None - - - 12.6 15
E10 10.6 1 10.2 15.1 20
E15 15.9 1 15.3 21.5 25
E20 21.2 2 20.4 27.9 30
E30 30.4 2 29.3 39 40
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
4. Electrical data for single phase gas heating units with belt drive is at the end of the electrical data section.
J03 through A6ZE - Without Powered Convenience Outlet (Belt Drive) (Continued)
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
Max
Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
