Table 7: Electrical Data
J03 through A6ZE - Without Powered Convenience Outlet (Belt Drive)
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
Max
Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
J03
(3.0)
208-1-60
4
15.4 83.9 24 2.3 6.7 0
NONE - - - 28.3 35
E05 4 1 19.2 32.4 40
E07 5.6 1 26.9 42 45
E10 8 1 38.5 56.5 60
E15 11.9 2 57.2 79.9 80
E20 15.9 2 76.4 103.9 110
230-1-60
4
15.4 83.9 24 2.3 6.7 0
NONE - - - 28.3 35
E05 5.3 1 22.1 36 40
E07 7.5 1 31.2 47.4 50
E10 10.6 1 44.2 63.6 70
E15 15.9 2 66.2 91.2 100
E20 21.2 2 88.3 118.8 125
208-3-60 10.4 73 16.3 2.3 4.3 0
NONE - - - 19.6 25
E05 4 1 11.1 19.6 25
E07 5.6 1 15.5 24.8 30
E10 8 1 22.2 33.1 35
E15 11.9 2 33 46.7 50
E20 15.9 2 44.1 60.5 70
230-3-60 10.4 73 16.3 2.3 4.3 0
NONE - - - 19.6 25
E05 5.3 1 12.7 21.3 30
E07 7.5 1 18 27.9 30
E10 10.6 1 25.5 37.2 40
E15 15.9 2 38.2 53.2 60
E20 21.2 2 51 69.1 70
460-3-60 5.8 38 9 1.3 2.1 0
NONE - - - 10.6 15
E07 6.8 1 8.2 12.8 15
E10 10.1 1 12.1 17.8 20
E15 13.6 2 16.4 23.1 25
E20 19.5 2 23.5 31.9 35
575-3-60 4.2 36.5 5.9 1.3 1.9 0
NONE - - - 8.2 15
E10 10.6 1 10.2 15.1 20
E15 15.9 2 15.3 21.5 25
E20 21.2 2 20.4 27.9 30
J04
(4.0)
208-1-60
4
19.6 130 30.5 2.3 6.7 0
NONE - - - 33.5 45
E05 4 1 19.2 33.5 45
E07 5.6 1 26.9 42 50
E10 8 1 38.5 56.5 60
E15 11.9 2 57.2 79.9 80
E20 15.9 2 76.4 103.9 110
230-1-60
4
19.6 130 30.5 2.3 6.7 0
NONE - - - 33.5 45
E05 5.3 1 22.1 36 45
E07 7.5 1 31.2 47.4 50
E10 10.6 1 44.2 63.6 70
E15 15.9 2 66.2 91.2 100
E20 21.2 2 88.3 118.8 125
208-3-60 13.7 83.1 21.4 2.3 4.3 0
NONE - - - 23.7 30
E05 4 1 11.1 23.7 30
E07 5.6 1 15.5 24.8 30
E10 8 1 22.2 33.1 35
E15 11.9 2 33 46.7 50
E20 15.9 2 44.1 60.5 70
230-3-60 13.7 83.1 21.4 2.3 4.3 0
NONE - - - 23.7 30
E05 5.3 1 12.7 23.7 30
E07 7.5 1 18 27.9 35
E10 10.6 1 25.5 37.2 40
E15 15.9 2 38.2 53.2 60
E20 21.2 2 51 69.1 70
460-3-60 6.2 41 9.7 1.3 2.1 0
NONE - - - 11.1 15
E07 6.8 1 8.2 12.8 15
E10 10.1 1 12.1 17.8 20
E15 13.6 2 16.4 23.1 25
E20 19.5 2 23.5 31.9 35
575-3-60 4.8 33 7.5 1.3 1.9 0
NONE - - - 8.9 15
E10 10.6 1 10.2 15.1 20
E15 15.9 2 15.3 21.5 25
E20 21.2 2 20.4 27.9 30
