Johnson Controls ATC1510 User Manual

Table 5: Termination diagrams
Type of Field
Device
Type of Input/
Output
Termination Diagrams
0–10 VDC Output
to Actuator
(External Source)
CO
0–10 VDC Output
to Actuator
(Internal Source)
CO
Current Output CO
24 VAC Triac
Output (Switch
Low, External
Source)
CO
Incremental
Control to
Actuator (Switch
Low, Externally
Sourced)
(Triac Jumpers
where applicable)
BO
24 VAC Binary
Output (Switch
Low, Externally
Sourced)
(Triac Jumpers
where applicable)
BO
24 VAC Binary
Output (Switch
High, Externally
Sourced)
(Triac Jumpers
where applicable)
BO
ATC1510 Advanced Terminal Unit Controller Installation Guide10
