Johnson Controls CK721-A Upgrade Manual

Factory Field Upgrade Manual CK721-A Version 3.0
24-10025-59 Rev. – 5
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2010 Johnson Controls, Inc.
 To Copy and Run the CK721-A Version 3.0 Self-Extracting Archive
File:
1. Copy the CK721a_Factory_FieldUpdate_FW_3.0.exe file to the PC’s C:\
directory.
2. Double-click the archive file.
The WinZip Self-Extractor dialog box appears.
3. Verify that C:\ is listed in the Unzip to folder field.
4. Click Unzip.
The self-extracting archive file will save the CK721-A Version 3.0
firmware files into the following directory structure:
C:\ck721a
The following files will be available in the ck721a subdirectories:
./CK721a/Step1:
 1image-721a-factory-field-ftpd001.bin
 load.bat
 load1.bat
 load2.bat
 sendnto.exe
./CK721a/Step2:
 2image.bin
 fs.tar
 step2b.sh
 step2a.bat
 step2a.ftp
5. Click OK when the files successfully extracted message appears.
 To Change the Computer’s IP Address:
1. On the Local Area Connection Properties dialog box, select Internet
Protocol (TCP/IP).
