Johnson Controls F4-CG Series User Manual

Table 11: CG series controller accessories (order separately)
Product Code Number Description
NS Series Network Sensors Refer to the NS Series Network Sensors Product Bulletin (LIT-12011574) for specific
sensor model descriptions.
AS-CBLTSTAT-0 Cable adapter for connection to 8-pin TE-6700 Series sensors
NS-WALLPLATE-0 Network Sensor Wall Plate
WRZ Series Wireless Room Sensors Refer to the WRZ Series Wireless Room Sensors Product Bulletin (LIT-12011653) for
specific sensor model descriptions.
WRZ-7860-0 Receiver for One-to-One Wireless Room Sensing Systems - functions with WRZ
Series Sensors room sensors.
Refer to the WRZ-7860 Receiver for One-to-One Wireless Room Sensing Product
Bulletin (LIT-12011640) for a list of available products.
WRZ-SST-120 Wireless System Survey Tool. For use with the lower power 10mW WRZ and
WRZ-7860 systems.
Refer to the WRZ-SST-120 Wireless Sensing System Tool Installation Instructions
(LIT-24-10563-55) for usage instructions.
ZFR-HPSST-0 Wireless System Survey Tool. For use with the higher power WRG1830/ZFR183x
System and lower power WRZ Sensors (10 mW). Refer to the ZFR-HPSST-0
Wireless Sensing System Tool Installation Guide (Part No. 24-11461-00012) for usage
instructions.
WRG1830/ZFR183x Pro Wireless Field Bus System For more information on products needed for wireless field bus installations and
for a list of available products, refer to the WRG1830/ZFR183x Pro Series Wireless
Field Bus System Catalog Page (LIT-1901153).
ZFR-USBHA-0 ZFR USB Dongle provides a wireless connection through CCT to allow wireless
commissioning of the wirelessly enabled CGM and CVM controllers. It also allows
use of the ZFR Checkout Tool (ZCT) in CCT.
Note: The ZFR-USBHA-0 is not compatible with the WRG1830/ZFR183x Pro
Series.
Note: The ZFR-USBHA-0 replaces the IA OEM DAUBI_2400 ZFR USB dongle.
For additional information about the ZFR-USBHA-0 ZFR dongle, refer to the
ZCT Checkout Tool Help (LIT-12012292) or the WNC1800_ZFR182x Pro Series
Wireless Field Bus System Technical Bulletin (LIT-12012356).
Y64T15-0 Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 92 VA, Foot Mount,
72.2 cm (30 in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65A13-0 Transformer, 120 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount (Y65AS),
20.32 cm (8 in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65T31-0 Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount
(Y65AR+), 20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
Y65T42-0 Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Hub Mount
(Y65SP+), 20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
ACC-TBKINOUT-0 Input and Output terminal block replacement kit for SNC, CGM, CGE, CVM, CVE,
and XPM products. Kit includes 5 of each 2, 3, and 4 position Input and Output
terminal blocks.
ACC-TBKPWFCSA-0 Power, FC Bus, and SA Bus terminal block replacement kit for SNC, CGM, CGE,
CVM, CVE, and XPM products. Kit includes 5 of each terminal block type.
MS-FIT100-0 The Field Inspection Tool or (FIT) is a portable handheld device with a user
interface that is used to test and troubleshoot the BACnet protocol MS/TP RS-485
communications bus that connects supervisory controllers and equipment
controllers to field point interfaces.
The FIT can be used to check out the wiring of the MS/TP RS-485 bus as well
as verify proper communications of supervisory controllers and equipment
controllers connected to the bus. The FIT can be used on both the FC Bus and SA
Bus.
TL-BRTRP-0 Portable BACnet/IP to MS/TP Router
F4-CG Series General Purpose Application Controllers Installation Guide 23
