Johnson Controls FCP-NA-701 User Manual

FCP-NA-701, FCP-PA-701
24-11482-00006 Rev. —
8
Menu item Description Setting options Default
28 Pipe state – calendar ON
OFF
OFF
29 Heat to cool day
(unavailable if pipe state – calendar = OFF)
1-Mar to 31-May 15-Apr
30 Cool to heat day
(unavailable if pipe state – calendar = OFF)
1-Sep to 30-Nov 15-Oct
31 Pipe state
(unavailable if system type ≠ 2FCU or if pipe
sensor = true or if pipe state – calendar = ON)
0: heat
1: cool
0
32 Heat to cool threshold
(unavailable if system type ≠ 2FCU or if pipe
sensor = false)
50°F - 72°F (10°C - 22°C) 60°F (16°C)
33 Cool to heat threshold
(unavailable if system type ≠ 2FC or if pipe sensor
= false)
55°F - 90°F (13°C - 32°C) 80°F (27°C)
34 Purge frequency
(unavailable if system type ≠ 2FC or if pipe sensor
= false)
0: Never
1: 2 hours
2: 24 hours
With pipe sensor: 1
Without pipe sensor: 0
Programmable mode (FCP-PA-701 only)
The programmable mode is available only on the FCP-PA-701 model. In the programmable mode menu you can adjust time of day,
date, schedule for heat, and schedule for cool.
To enable the programmable mode, complete the following steps:
1. Press Mode to set the thermostat to OFF mode.
2. Press and hold Mode and Fan for 5 seconds to access the advanced settings menu.
3. Press Up to navigate to User Preference Settings, then press Mode to enter the menu.
4. Press Mode to navigate to 10.
5. Use the Up and Down buttons to set the programmable mode to ON and press Mode to conrm the change.
To access the programmable mode, press Mode to set the thermostat to OFF mode, then press and hold Mode and Up for 5 seconds.
Setting the time and date
To set the time and date, complete the following steps:
1. In the progrmmable mode, press Mode to access the Set Time menu.
2. In the Set Time menu, press Mode to scroll through the menu and press Up or Down to change the options.
3. After each change, press Mode to conrm the change.
4. After you set all the options in the Set Clock menu, press Mode to continue to set the schedule, or press Fan to exit the menu and
retun to the home screen.
Setting the heat and cool schedule
You can program a schedule for up to seven consecutive days. Each day can consist of a maximum of six periods. You can change the
start times for each period by increments of 15 minutes.
To set the heat and cool schedule, complete the following steps:
1. In the programmable mode, press Up or Down to navigate to the heat icon, then press Mode to access the menu.
2. Press Up or Down to select the day of the week you want to schedule, then press Mode to conrm the selection.
3. Press Mode to navigate to the following setting and press Up or Down to set the required period and temperature. Repeat this step
until you set all the schedule settings.
4. Press Mode to save the settings and return to Set Sche menu.
5. Press Up or Down to navigate to the cool icon and press Mode to access the menu.
6. Repeat Step 3 and Step 4 until you set all the schedule settings.
Remote sensor
The system conguration summary indicates if a remote sensor is installed. Access the advanced settings menu to see your system
conguration summary.
You can adjust the values of the temperature o󰀨set to calibrate the remote sensor temperature.
Table 6: System conguration settings (part 2 of 2)
