2-Wire Auxiliary Device without C Terminal
An auxiliary device that has two terminals with the same label (HUM, DEHUM, or
AUX) and no C terminal requires a relay pack for operation.
1. Connect the relay pack coil between the auxiliary device and C terminal on your
GLAS device.
2. Connect the switch side of the relay pack to the two terminals on the AUX device.
