Johnson Controls GLAS User Manual

Terminal descriptions
Note: If you have only one R wire, connect to RC.
Note: If you are replacing an existing thermostat, remove any jumper wires between
R and RH or RC and RH.
Y First stage of cooling or rst stage heat pump
Y2 Second stage of cooling command or second stage heat pump
W First stage of conventional heating or rst stage auxiliary heat for heat pump
systems
W2 Second stage of conventional heating or second stage of auxiliary heat for
heat pump system

Johnson Controls GLAS Specifications

General

Brand	Johnson Controls
Model	GLAS
Category	Thermostat
Language	English
