Johnson Controls GVC Series User Manual

Johnson Controls
5586996-JSG-A-0120 | Start-Up & Operation Guide
106
BACnet
Attributes
Object
Type
Object
ID
Read/
Write
Short Description
Long
Description
Point Denitions (Units)
SZVAVHtgMinFan AV 30035 R/W SZVAVHtgMinFan
SZVAV Heating
Minimum Fan
Speed
A BAS command to adjust SZVAV
heating minimum fan speed (20–67%)
UVLight-Rt AV 30038 R UVLight-Rt UV Light Runtime Displays the UV light runtime (hours)
DLP1 AV 30040 R DLP1
Discharge Line
Pressure 1
Displays the active system 1
discharge line pressure (psi)
DLT1 AV 30041 R DLT1
Discharge Line
Temperature 1
Displays the active system 1
discharge line temperature (°F)
DLP2 AV 30042 R DLP2
Discharge Line
Pressure 2
Displays the active system 2
discharge line pressure (psi)
DLT2 AV 30043 R DLT2
Discharge Line
Temperature 2
Displays the active system 2
discharge line temperature (°F)
DischSuperheat1 AV 30044 R DischSuperheat1
Discharge
Superheat 1
Displays the active system 1
discharge superheat temperature (°F)
DischSuperheat2 AV 30045 R DischSuperheat2
Discharge
Superheat 2
Displays the active system 2
discharge superheat temperature (°F)
SucSuperheat1 AV 30046 R SucSuperheat1
Suction
Superheat 1
Displays the active system 1 suction
superheat temperature (°F)
SucSuperheat2 AV 30047 R SucSuperheat2
Suction
Superheat 2
Displays the active system 2 suction
superheat temperature (°F)
LLSubcool1 AV 30048 R LLSubcool1
Liquid Line Sub-
Cooling 1
Displays the active system 1 liquid
line sub-cooling temperature (°F)
LLSubcool2 AV 30049 R LLSubcool2
Liquid Line Sub-
Cooling 2
Displays the active system 2 liquid
line sub-cooling temperature (°F)
SatDischTemp1 AV 30050 R SatDischTemp1 Saturated DAT 1
Displays the active system 1
saturated DAT (°F)
SatDischTemp2 AV 30051 R SatDischTemp2 Saturated DAT 2
Displays the active system 2
saturated DAT (°F)
SatLLTemp1 AV 30052 R SatLLTemp1
Saturated Liquid
Line Temperature 1
Displays the active system 1
saturated liquid line temperature (°F)
SatLLTemp2 AV 30053 R SatLLTemp2
Saturated Liquid
Line Temperature 2
Displays the active system 2
saturated liquid line temperature (°F)
SatSucTemp1 AV 30054 R SatSucTemp1
Saturated Suction
Temperature 1
Displays the active system 1 saturated
suction line temperature (°F)
SatSucTemp2 AV 30055 R SatSucTemp2
Saturated Suction
Temperature 2
Displays the active system 2 saturated
suction line temperature (°F)
H8-Starts AV 30056 R H8-Starts
Heating Number
Times ON 8
Displays the heating start counts for
stage 8
DehumEvapLowSp AV 30061 R/W DehumEvapLowSp
Dehum Evap Low
Setpoint
A BAS command to adjust
dehumidication evaporator low
setpoint (40°F)
Name CSV 29804 R/W Name Unit Name Displays the unit name
Serial# CSV 29806 R/W Serial#
Unit Serial
Number
Displays the unit serial number
FirmVer CSV 29807 R FirmVer Firmware Version Displays the rmware version
DevName CSV 29818 R/W DevName Device Name A BAS command to input device name
Table 32: BACnet Points List (Continued)
