Johnson Controls, Inc. SLC Wiring Manual — P/N 51870:G 04/23/2009 67
Canadian Versions of SLC Devices
M300DJ M300DJA (CLIP) Two independent 2-wire Initiating Device Circuits (IDCs) at
two separate, consecutive addresses. Wire supervised IDCs
as NFPA Style B (Class B) or Style D (Class A) circuits. The
modules come with a thermoplastic cover for mounting to a
4-inch (10.16 cm) square mounting box.
M301MJ M301MJA Functionally similar to the M300MJ Monitor Module, but
offered in a smaller package for mounting directly in the
electrical box of the device being monitored. (Class B input
circuit only.)
JBG-12LX JBG-12LXA An addressable manual pull station with key-lock reset
feature. The addressable module is housed within the pull
station.
Control Modules
M300CJ M300CJA Control Module, NAC: Addressable Control Module used as
Notification Appliance Circuits (NACs) to power and
supervise compatible, UL-listed notification appliances.
Wired supervised NACs as NFPA Style Y (Class B) or Style
Z (Class A). The modules come with a thermoplastic cover
for mounting to a 4-inch (10.16 cm) square mounting box.
M300RJ M300RJA Relay Control Module is similar to the M300CJ except used
as a Form-C control relay module.
Fault Isolator Module
M500XJ M500XJA The Fault Isolator Module protects the system against wire-
to-wire short circuits on the SLC. It should be placed
between groups of sensors in a Style 6 or Style 7 SLC to
isolate short- and open-circuit problems and protect the rest
of the loop so it can continue to operate normally. It is not
addressable, but listed here due to its use in an SLC
Multi-input/output modules
XPIQ XPIQ Quad Intelligent Audio Transponder - The XPIQ is an
integrated audio amplification and distribution subsystem
that can direct up to four low-level audio signals through four
audio amplifiers to integrated, continuously supervised
speaker circuits. An on-board power supply charges and
supervises battery backup.
XP6-C XP6-CA Controls six NAC or speaker/telephone circuits. (Not listed
for use in releasing applications.)
XP6-R XP6-RA Controls six Form-C relays.
XP10-M
XP10-MA
Supervises ten Class-B addressable Initiating Device
Circuits (IDC) which monitor normally open contact initiating
devices.
XP6-MA
XP6-MAA
Monitors six zones of conventional two-wire detectors.
UL-listed SLC Device ULC-listed SLC Device
