Johnson Controls L-Series User Manual

FORM 145.05-EG2 (618)
JOHNSON CONTROLS
31
TABLE 17 - LSWU105
AIR FLOW 36,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 1214 991.3 50.0 49.9 67.5 288.9 1204 986.7 50.1 50.0 69.0 239.9 1189 979.6 50.3 50.2 71.2 286.3
75 67 1315 790 55.4 55.3 69.3 310.3 1306 786.1 55.5 55.4 70.7 257.8 1289 779.4 55.7 55.6 72.9 307.6
75 72 1422 588 60.8 60.8 71.3 333.1 1411 584 60.9 60.9 72.7 276.5 1394 578 61.1 61.1 74.8 329.8
80 62 1262 1197 49.7 49.3 68.4 299.0 1253 1192 49.8 49.4 69.8 248.6 1240 1185 50.0 49.6 72.0 297.0
80 67 1316 986.4 55.3 55.2 69.3 310.5 1307 982.6 55.4 55.3 70.7 258.1 1292 976.3 55.6 55.5 72.9 308.1
80 72 1424 783.3 60.8 60.7 71.3 333.5 1414 779.6 60.9 60.8 72.7 276.9 1396 773 61.1 61.0 74.8 330.3
85 62 1324 1324 51.4 48.6 69.4 312.2 1315 1315 51.6 48.7 70.9 259.5 1303 1303 51.9 48.8 73.1 310.5
85 67 1352 1193 55.0 54.8 69.9 318.0 1343 1189 55.1 54.9 71.3 264.3 1328 1182 55.2 55.1 73.6 315.7
85 72 1425 979.7 60.7 60.6 71.3 333.8 1415 975.7 60.8 60.7 72.7 277.1 1398 969.4 61.0 60.9 74.9 330.7
AIR FLOW 36,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 1180 975.6 50.4 50.3 72.7 238.0 1165 968.7 50.6 50.5 75.2 284.3 1164 968.9 50.6 50.5 77.0 237.8
75 67 1278 774.7 55.8 55.7 74.4 255.3 1261 768.1 56.0 55.9 76.8 304.6 1251 764.2 56.1 56.0 78.3 253.1
75 72 1383 573 61.2 61.1 76.3 273.9 1366 567 61.4 61.3 78.7 326.9 1354 563 61.4 61.4 80.2 271.3
80 62 1230 1181 50.1 49.7 73.6 246.9 1215 1173 50.3 49.9 76.1 294.8 1206 1168 50.4 50.0 77.6 245.2
80 67 1280 971.5 55.7 55.6 74.4 255.7 1264 964.8 55.9 55.8 76.8 305.1 1253 960.6 56.0 55.9 78.4 253.5
80 72 1385 768.9 61.1 61.1 76.4 274.2 1367 762.3 61.3 61.2 78.7 327.0 1356 758.4 61.4 61.3 80.3 271.6
85 62 1294 1294 52.1 48.9 74.7 258.1 1279 1279 52.5 49.1 77.2 308.5 1271 1271 52.7 49.2 78.7 256.6
85 67 1317 1177 55.4 55.2 75.1 262.2 1301 1169 55.6 55.3 77.6 313.2 1292 1165 55.7 55.4 79.2 260.3
85 72 1387 965.4 61.1 61.0 76.4 274.6 1369 958.7 61.2 61.1 78.7 327.5 1358 954.7 61.3 61.2 80.3 272.0
HIGH EFFICIENCY - AIR FLOW 28,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 1237 915.2 45.5 45.4 68.0 293.7 1227 910.7 45.7 45.6 69.4 244.0 1213 904 45.9 45.8 71.6 291.6
75 67 1332 749.6 51.3 51.2 69.6 313.8 1321 745.2 51.4 51.3 71.0 260.6 1305 738 51.6 51.5 73.2 310.9
75 72 1444 588 56.8 56.8 71.7 337.7 1433 583.7 56.9 56.9 73.1 280.4 1415 576.8 57.2 57.1 75.2 334.4
80 62 1263 1084 44.9 44.8 68.4 299.3 1255 1080 45.0 44.9 69.9 249.0 1242 1073 45.2 45.1 72.1 297.7
80 67 1334 907 51.0 50.9 69.6 314.3 1324 902.5 51.2 51.1 71.0 261.0 1306 892.5 51.5 51.4 73.2 311.1
80 72 1445 744 56.7 56.6 71.7 337.9 1435 740 56.8 56.7 73.1 280.7 1417 733 57.0 56.9 75.3 334.8
85 62 1312 1261 43.9 43.8 69.3 309.6 1302 1256 44.1 44.0 70.7 257.3 1288 1248 44.4 44.3 73.0 307.4
85 67 1361 1075 50.4 50.3 70.1 320.1 1351 1071 50.5 50.4 71.5 265.9 1336 1064 50.7 50.6 73.7 317.5
85 72 1448 902 56.4 56.3 71.7 338.5 1437 897.8 56.6 56.5 73.1 281.1 1419 890.5 56.8 56.7 75.3 335.1
HIGH EFFICIENCY - AIR FLOW 28,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 1204 899.4 46.0 45.9 73.2 242.3 1188 891.9 46.3 46.2 75.6 289.2 1178 887 46.4 46.3 77.2 240.2
75 67 1294 733.5 51.8 51.7 74.7 258.2 1277 726.1 52.0 51.9 77.1 308.1 1267 721.7 52.1 52.0 78.7 255.9
75 72 1405 572.7 57.2 57.2 76.7 277.7 1385 565.2 57.5 57.5 79.1 331.0 1374 560.7 57.7 57.6 80.6 274.8
80 62 1232 1068 45.4 45.3 73.7 247.3 1218 1061 45.6 45.5 76.1 295.6 1208 1056 45.8 45.7 77.8 245.6
80 67 1297 890.7 51.5 51.4 74.7 258.6 1279 883 51.8 51.7 77.1 308.4 1268 878.5 51.9 51.8 78.7 256.1
80 72 1406 728.9 57.2 57.1 76.7 278.0 1387 721.2 57.4 57.3 79.1 331.3 1376 716.9 57.5 57.4 80.7 275.1
85 62 1279 1244 44.5 44.4 74.5 255.5 1263 1236 44.7 44.6 77.0 305.2 1254 1231 44.9 44.8 78.6 253.7
85 67 1325 1059 50.9 50.8 75.3 263.7 1308 1052 51.1 51.0 77.6 314.6 1298 1047 51.3 51.2 79.2 261.4
85 72 1407 886 56.9 56.8 76.8 278.2 1388 878.6 57.2 57.1 79.2 331.7 1378 874.5 57.3 57.2 80.7 275.5
NOTE: EDB-entering dry bulb temp, EWB-entering wet bulb temp, EWT-entering water temp, LWT-leaving water temp, LDB-leaving dry bulb temp,
LWB-leaving wet bulb temp, TMBH-total capacity, SMBH-sensible capacity
