Johnson Controls L-Series User Manual

FORM 145.05-EG2 (618)
32
JOHNSON CONTROLS
TABLE 18 - WATERSIDE ECONOMIZER COIL
MODEL AIR FLOW LDB LWB TMBH SMBH WATER FLOW GPM
LSWU025
7,200 63.4 57.6 94.2 90.7 71.8
8,850 64.3 58.0 104.0 102.1 71.8
10,500 65.2 58.4 112.4 111.8 71.8
LWSU025 - HIGHEFF
6,300 62.7 57.3 88.0 83.6 73.3
7,450 63.5 57.7 95.9 92.6 73.3
8,600 64.2 58.0 102.8 100.6 73.3
LSWU032
9,000 63.4 57.6 117.9 113.5 92.8
11,150 64.4 58.1 130.8 128.4 92.8
13,300 65.2 58.4 141.7 141.0 92.8
LWSU032 - HIGHEFF
7,800 62.7 57.2 109.7 104.0 94.4
9,400 63.6 57.7 120.6 116.5 94.4
11,000 64.3 58.0 130.1 127.4 94.4
LSWU035
10,800 63.4 57.6 140.5 135.9 99.9
13,150 64.3 58.0 154.4 151.9 99.9
15,500 65.1 58.4 166.2 165.6 99.9
LWSU035 - HIGHEFF
9,400 62.7 57.3 131.2 125.2 101.3
11,300 63.6 57.7 143.9 139.7 101.3
13,200 64.3 58.1 154.8 152.4 101.3
LSWU040
10,800 63.4 57.6 141.6 136.2 113.0
13,400 64.4 58.1 157.3 154.3 113.0
16,000 65.2 58.4 170.3 169.4 113.0
LWSU040 - HIGHEFF
9,400 62.7 57.2 132.0 125.2 113.3
11,300 63.6 57.7 144.9 140.0 113.3
13,200 64.3 58.0 156.1 152.9 113.3
LSWU050
16,000 63.3 57.7 205.0 202.2 140.9
18,000 63.9 57.9 216.9 215.9 140.9
20,000 64.5 58.2 227.0 227.0 140.9
LWSU050 - HIGHEFF
14,100 62.7 57.4 192.7 188.0 141.1
17,050 63.6 57.8 211.3 209.5 141.1
20,000 64.5 58.2 227.1 227.1 141.1
LSWU060
16,000 63.3 57.6 208.1 203.4 167.9
20,000 64.3 58.1 231.5 230.7 167.9
24,000 65.4 58.5 249.2 249.2 167.9
LWSU060 - HIGHEFF
14,100 62.7 57.3 195.4 188.7 168.2
17,050 63.6 57.7 214.6 211.0 168.2
20,000 64.3 58.1 231.6 230.7 168.2
LSWU070
19,900 63.3 57.6 255.9 248.1 200.4
24,850 64.4 58.1 284.7 281.4 200.4
29,800 65.3 58.5 308.5 308.5 200.4
LWSU070 - HIGHEFF
19,900 63.4 57.6 252.7 247.0 168.7
22,350 63.9 57.9 267.2 263.8 168.7
24,800 64.4 58.1 280.2 278.8 168.7
LSWU080
22,600 63.3 57.6 294.7 286.1 224.7
28,250 64.4 58.1 327.7 324.3 224.7
33,900 65.3 58.5 354.9 354.9 224.7
LWSU080 - HIGHEFF
22,600 63.3 57.6 294.7 286.1 224.7
25,400 63.9 57.9 312.0 306.0 224.7
28,200 64.4 58.1 327.4 323.9 224.7
LSWU095
24,200 63.3 57.6 317.4 306.2 272.7
30,150 64.3 58.1 353.4 347.9 272.7
36,100 65.2 58.4 383.3 382.5 272.7
LWSU095 - HIGHEFF
24,200 63.3 57.6 317.8 306.2 278.3
27,150 63.8 57.8 336.7 328.1 278.3
30,100 64.3 58.0 353.5 347.7 278.3
LSWU105
24,200 63.3 57.5 319.5 306.4 308.1
30,150 64.3 58.0 356.2 348.9 308.1
36,100 65.2 58.4 386.9 384.7 308.1
LWSU105 - HIGHEFF
24,200 63.3 57.5 319.7 306.4 311.1
27,150 63.8 57.8 338.9 328.6 311.1
30,100 64.3 58.0 356.1 348.6 311.1
