16 M Motor Actuators—M100C Series of Motor Actuators
C500 Controllers are factory programmed for specific applications.
Different models of C500 Controllers may use the same address number
for different functions. For example; the Single Zone C500A Controller
uses Address 17 for the full range heating actuator, but the Three Loop
C500B Controller uses Address 17 for controlling a cooling actuator.
Therefore, before positioning the address switches, refer to the specific
C500 Controller technical bulletin to find the address values that
correspond to the exact motor actuator functions desired.
M100C12
45 678
OFF
Address 10
45
67
8
OFF
Address 11
4
5
678
OFF
Address 12
45
6
78
OFF
Address 13
45 678
OFF
Address 14
45 678
OFF
Address 15
45 6
7
8
OFF
Address 16
4
567
8
OFF
Address 17
45 678
OFF
Address 20
45 678
OFF
Address 21
45 6
7
8
OFF
Address 22
4
567
8
OFF
Address 23
45 678
OFF
Address 24
45 6
7
8
OFF
Address 25
4
567
8
OFF
Address 26
45
67
8
OFF
Address 27
Figure 15: C500 Address Switch Settings
Table 5: C500 Address Switch Values
SWITCH NUMBER ON VALUE OFF VALUE
5
010
6
04
7
02
8
01
When selecting L1 Bus, add an additional value of 10 to the total of the
switch settings. For example: to select L1 Address 15, set Switches 6
and 8 OFF and Switches 5 and 7 ON (15 = 0 + 4 + 0 + 1 from the switch
settings and +10 because of L1 Bus selection). Using the switches, any L1
address from 10 to 27 is selectable with the exception of Addresses 18 and
19 that are not available.
C500 Controller
Address Selection
