Page #23 background imageLoading...
Page #23 background image
Ordering information and
accessories
The following tables provide the product code number and description for the CGM models and accessories.
Table 12: CGM Series ordering information
Product code number Description
M4-CGM09090-0
General Purpose Application Controller
Includes: MS/TP (and N2) communication; 18 points (7 UI, 2 BI, 4 CO, 2 AO, 3 BO); real-time clock; 32-bit
microprocessor; 24VAC input
Table 13: CGM Controller accessories (order separately)
Product Code Number Description
IOM Series Controllers
Refer to the Metasys
®
System Field Equipment Controllers and Related Products
Product Bulletin (LIT-12011042) for a complete list of available IOM Series
Controllers.
TL-CCT-0
License enabling Metasys Controller Configuration Tool (CCT) software for one
user
MS-FCP-0
License enabling Metasys Equipment Controller Firmware Package Files required
for CCT
Mobile Access Portal (MAP) Gateway
Refer to the Mobile Access Portal Gateway Catalog Page (LIT-1900869) to identify the
appropriate product for your region.
Note: The MAP Gateway serves as a replacement for the BTCVT, which is no
longer available for purchase, but continues to be supported.
MS-DIS1710-0 Local Controller Display
NS Series Network Sensors
Refer to the NS Series Network Sensors Product Bulletin (LIT-12011574) for specific
sensor model descriptions.
AS-CBLTSTAT-0 Cable adapter for connection to 8-pin TE-6700 Series sensors
NS-WALLPLATE-0 Network Sensor Wall Plate
WRZ Series Wireless Room Sensors
Refer to the WRZ Series Wireless Room Sensors Product Bulletin (LIT-12000653) for
specific sensor model descriptions.
WRZ-7860-0
Refer to the WRZ-7860 Receiver for One-to-One Wireless Room Sensing Product
Bulletin (LIT-12011640) for a list of available products.
WRZ-SST-120
Refer to the WRZ-SST-120 Wireless Sensing System Tool Installation Instructions
(LIT-24-10563-55) for usage instructions.
WNC1800/ZFR182x Pro Wireless Field Bus System
Refer to the WNC1800/ZFR182x Pro Series Wireless Field Bus System Product Bulletin
(LIT-12012320) for a list of available products.
ZFR1800 Series Wireless Field Bus System
Refer to the ZFR1800 Series Wireless Field Bus System Product Bulletin (LIT-12011336)
for a list of available products.
ZFR-USBHA-0
ZFR USB Dongle provides a wireless connection through CCT to allow wireless
commissioning of the wirelessly enabled CGM, CVM, FAC, FEC, VMA16, and IOM
controllers. It also allows use of the ZFR Checkout Tool (ZCT) in CCT.
Note: The ZFR-USBHA-0 replaces the IA OEM DAUBI_2400 ZFR USB dongle.
For additional information about the ZFR-USBHA-0 ZFR dongle, refer to the
ZCT Checkout Tool Help LIT-12012292 or the WNC1800_ZFR182x Pro Series
Wireless Field Bus System Technical Bulletin (LIT-12012356).
Y64T15-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 92 VA, Foot Mount,
72.2 cm (30 in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65A13-0
Transformer, 120 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount (Y65AS),
20.32 cm (8 in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65T31-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount
(Y65AR+), 20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
Y65T42-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Hub Mount
(Y65SP+), 20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
M4-CGM General Purpose Application Controllers Installation Guide 23
