I/O terminal blocks, ratings and
requirements
Table 5: I/O terminal blocks, functions, ratings, requirements, and cables
Terminal Block label Terminal labels Function, ratings, and requirements
To determine wire size and
maximum cable length
+15 V
15 VDC Power Source for active (3-wire) input
devices connected to the Universal INn terminals.
Provides 35 mA total current.
Same as (Universal) INn.
Note: Use 3-wire cable for
devices that source power
from the +15 V terminal.
Analog Input - Voltage Mode (0–10 VDC)
10 VDC maximum input voltage
Internal 75k ohm Pulldown
See Guideline A in Table 6.
Analog Input - Resistive Mode (0–600k ohm)
Internal 12 V, 15k ohm pull up
Qualified Sensors: 0–2k potentiometer
RTD (1k Nickel [Johnson Controls sensor]
1k Platinum, and A99B Silicon Temperature Sensor)
Negative Temperature Coefficient (NTC) Sensor
10K Type L (10K Johnson Controls Type II is
equivalent to Type L) or 2.252K Type II
See Guideline A in Table 6.INn
Binary Input - Dry Contact Maintained Mode
1 second minimum pulse width
Internal 12 V, 15k ohm pull up
See Guideline A in Table 6.
UNIVERSAL
(Inputs)
ICOMn
Universal Input Common for all Universal IN
terminals
Note: All Universal ICOMn terminals are
isolated from all other commons.
Same as (Universal) INn.
Analog Output - Voltage Mode (0–10 VDC)
10 VDC maximum output voltage
10 mA maximum output current
External 1k to 50k ohm load required
See Guideline A in Table 6.
OUTn
Binary Output 24 VAC Triac
Connects OUT to OCOM when activated.
External Power Source:
30 VAC maximum voltage to load
0.5 A maximum output current
1.3 A at 25% duty cycle
40 mA minimum load current
See Guideline C in Table 6.
Analog Output Signal Common: All Configurable
Outputs defined as Analog Outputs share a
common, which is isolated from all other commons
except the Binary Input common.
CONFIGURABLE
(Outputs)
OCOMn
Binary Output Signal Common: All Configurable
Outputs defined as Binary Outputs are isolated
from all other commons, including other
Configurable Output commons.
Same as (Configurable) OUTn.
M4-CVM03050 VAV Controllers Installation Guide 9
