Table 12: XPM series accessories (order separately)
Product Code Number Description
Receiver for One-to-One Wireless Room Sensing
WRG1830/ZFR183x Pro Series Wireless Field Bus
System
For more information on products needed for wireless field bus installations and
for a list of available products, refer to the WRG1830/ZFR183x Pro Series Wireless
Field Bus System Catalog Page (LIT-1901153).
Y64T15-0 Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 92 VA, Foot Mount,
72.2 cm (30 in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65A13-0 Transformer, 120 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount (Y65AS),
20.32 cm (8 in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65T31-0 Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount
(Y65AR+), 20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
Y65T42-0 Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Hub Mount
(Y65SP+), 20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
ACC-TBKINOUT-0 Input and Output terminal block replacement kit for SNC, CGE, CGM, CVE, CVM
and XPM products. Kit includes 5 of each 2, 3, and 4 position Input and Output
terminal blocks. 30 terminal blocks in total.
ACC-TBKPWFCSA-0 Power, FC Bus, and SA Bus terminal block replacement kit for SNC, CGE, CGM, CVE,
CVM, and XPM products. Kit includes 5 of each terminal block type. 15 terminal
blocks in total.
MS-FIT100-0 The Field Inspection Tool or (FIT) is a portable handheld device with a user
interface that is used to test and troubleshoot the BACnet protocol MS/TP RS-485
communications bus that connects supervisory controllers and equipment
controllers to field point interfaces.
The FIT can be used to check out the wiring of the MS/TP RS-485 bus as well
as verify proper communications of supervisory controllers and equipment
controllers connected to the bus. The FIT can be used on both the FC Bus and SA
Bus.
TL-BRTRP-0 Portable BACnet/IP to MS/TP Router
XPM Expansion Modules technical specifications
Table 13: Technical specifications
Power requirement 24 VAC (nominal, 20 VAC minimum/30 VAC maximum), 50/60 Hz, Power Supply Class 2
(North America), Safety Extra-Low Voltage (SELV) (Europe)
Power consumption 14 VA maximum
Note: The VA rating does not include any power supplied to the peripheral devices
connected to Binary Outputs (BOs) or Configurable Outputs (COs), which can
consume up to 12 VA for each BO or CO; for a possible total consumption of an
additional 84 VA (maximum).
Power source +15 VDC power source terminals provide 100 mA total current.
Note: Only present on XPM09090 and XPM04060 models.
• M4-XPM09090-0: Quantity 2-located in Universal Input terminals for active (3-wire)
input devices.
• M4-XPM04060-0: Quantity 1-located in Universal Input terminals for active (3-wire)
input devices.
Ambient conditions Operating: 0°C to 50°C (32°F to 122°F); 10% to 90% RH noncondensing
Storage: -40°C to 80°C (-40°F to 176°F); 5% to 95% RH noncondensing
Network engines All network engine model types
Communications protocol BACnet MS/TP; Zigbee Wireless also supported (at FC Bus and for Sensors) with additional
hardware.
XPM expansion modules support Zigbee wireless functionality for the FC bus and for
sensors with additional hardware.
Device addressing for BACnet MS/TP Decimal address set using the three rotary switches; valid controller device addresses
4-127
M4-XPM Expansion Modules Installation Guide20
