M9220-GGx-3 Proportional Electric Spring Return Actuators Installation Guide
15
Mechanical Connections Standard
Shaft Clamp
Included with
Actuator
1/2 to 3/4 in. or 12 to 19 mm diameter round shafts, or
3/8 and 1/2 in. or 10, 12, and 14 mm square shafts
Optional
M9220-600
Jackshaft
Coupler Kit
3/4 to 1-1/16 in. or 19 to 27 mm diameter round shafts, or
5/8 and 3/4 in. or 16, 18, and 19 mm square shafts
Aluminum Enclosure NEMA 2 (IP54) for all mounting orientations
Ambient Conditions Operating -40 to 131°F (-40 to 55°C); 90% RH maximum, noncondensing
Storage -85 to 185°F (-65 to 85°C); 95% RH maximum, noncondensing
Dimensions See Figure 1.
Compliance United States UL Listed, CCN XAPX, File E27734; to UL 60730-1,
Automatic Controls for Household and Similar Use:, and UL 60730-2-14
Part 2, Particular Requirements for Electric Actuators (Models: All)
Canada UL Listed, CCN XAPX7, File E27734; to CAN/CSA E60730-1,
Automatic Controls for Household and Similar Use: and CAN/CSA
E60730-2-14 Part 2, Particular Requirements for Electric Actuators
(Models: All)
Europe CE Mark - Johnson Controls declares that this product is in compliance
with the essential requirements and other relevant provisions of the EMC
Directive and Low Voltage Directive.
Australia and
New Zealand
RCM Mark, Australia/NZ Emissions Compliant
(ModeIs: All M9220-xGx and M9220-xDx)
Shipping Weight 6.4 lb (2.9 kg)
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond
these specifications, consult the local Johnson Controls office. Johnson Controls shall not be liable for damages resulting from
misapplication or misuse of its products.
M9220-GGx Proportional Electric Spring Return Actuators (Part 2 of 2 )
Product warranty
This product is covered by a limited warranty, details of which can be found at www.johnsoncontrols.com/buildingswarranty.
Patent
Patents: http://jcipat.com
