M9220-GGx-3 Proportional Electric Spring Return Actuators Installation Guide
2
Installation
The M9220-GGx-3 Proportional Electric Spring Return
Actuators mount directly to the surface in any
convenient orientation using two M3 x 9.5 mm
self-drilling sheet metal screws and the anti-rotation
bracket (parts included with the actuator). No additional
linkages or couplers are required. Electrical
connections are color-coded and identified with
numbers permanently marked on the actuator cable.
A tag on the actuator cable identifies the electrical
connections, and wiring details are also included on the
actuator housing.
Parts Included
• Proportional electric spring return actuator with
coupler
• Anti-rotation bracket
• Manual override crank
• Two M3 x 9.5 mm self-drilling sheet metal
mounting screws
• Two No. 10-32 x 9/16 in. thread-forming conduit
screws
Special Tools Needed
• Torque wrench with 3/8 in. (10 mm) socket
• Digital voltmeter
• Flat blade screwdriver
IMPORTANT: Do not install or use this
M9220 GGx-3 Proportional Electric Spring Return
Actuator in or near environments where corrosive
substances or vapors could be present. Exposure of
the electric actuator to corrosive environments may
damage the internal components of the device, and
will void the warranty.
