M9220-GGx-3 Proportional Electric Spring Return Actuators Installation Guide
3
Dimensions
Figure 1: M9220-GGx-3 Proportional Electric Spring Return Actuator Dimensions, in. (mm)
A
4
(102)
10-5/16
(262)
2-3/16
(56)
FIG:M9210_ 9220_dimen
1-3/4
(44)
1/8
(3)
3-3/16
(81)
3/4
(19)
2-3/16
(56)
1
(25)
2
(51)
1-19/32
(40)
1-1/16
(27)
1/4 (6.5)
Mounting Hole
(6 Locations)
1-19/32
(40)
1-19/32
(40)
6-15/16
(176)
10
(254)
