Johnson Controls Metasys VMA1610 User Manual

Table 3: Termination Details
Termination DiagramsType of
Input/Output
Type of Field Device
SA BusNetwork Stat with
Terminals Addressable
SA BusNetwork Stat with
Terminals (Fixed
Address = 199)
Maximum Cable Length versus
Load Current
Use Figure 7 to estimate the maximum cable length
relative to the wire size and the load current (in mA) when
wiring inputs and outputs.
12VMA1610 and VMA1620 Variable Air Volume Controllers Installation Instructions
