PEAK® OEM 18 240 Volt SMART Equipment Controller Installation Instructions
21
Commissioning the Controllers
Commission the PEAK OEM 18 controller with CCT 10.3 with the OEM package. The programming is finalized by
the OEM or the Johnson Controls Center of Excellence for application development. You cannot modify this
application in the field; changes must be completed by the OEM. All configuration and parameter changes are
completed through the local display or MAP Gateway.
Troubleshooting Field Controllers
Observe the Status LEDs on the front of the controller and see Table 7 to troubleshoot the controller.
Accessories
Repair Information
If the PEAK OEM controllers fail to operate within their specifications, replace the controller. For a replacement
controller, contact your local OEM
representative.
Table 7: Status LEDs and Descriptions of LED States
LED Label LED Color Normal LED
State
Description of LED States
POWER Green On Steady Off Steady = No Supply Power. Check Output wiring for short
circuits and cycle power to the controller.
On Steady = Power Connected
FAULT Red Off Steady Off Steady = No Faults
On Steady = Device Fault: no application loaded; Main Code
download required if controller is in Boot mode, or a firmware
mismatch exists between the PEAK OEM and the ZRF1811
Wireless Field Bus Router.
Blink - 2 Hz = Download or Startup in progress, not ready for
normal operation
SA BUS Green Blink - 2 Hz Blink - 2 Hz = Data Transmission (normal communication)
Off Steady = No Data Transmission (Auto baud in progress)
On Steady = Communication lost, waiting to join.
FC BUS Green Blink - 2 Hz Blink - 2 Hz = Data Transmission (normal communication)
Off Steady = No Data Transmission (Auto baud in progress)
On Steady = Communication lost, waiting to join.
MOD BUS Green Blink - 2 Hz Blink - 2 Hz = Data Transmission (normal communication)
Off Steady = No Data Transmission (Auto baud in progress)
On Steady = Communication lost, waiting to join.
Table 8: Accessories Information
Product Code Number Description
PK-KIT1811-0 PEAK OEM 18 240 Volts removable terminal block kit for all spade connections
MS-BACEOL-0 Terminator module providing EOL termination on FC Bus and N2 segments
