VFD68 Variable Frequency Drives (575 VAC)
9
See Figure 6 and Table 5 for mounting space requirements.
Table 5: Required Clearance
Dimension 3.7 kW (5 HP) or Less 5.5 to 7.5 kW (7-1/2 to 10 HP)
A 100 mm (4 in.) or more 100 mm (4 in.) or more
B 10 mm (7/16 in.) or more 50 mm (2 in.) or more
C
Figure 6: Required Clearance for Mounting Inside an Enclosure
5.5 to 7.5 kW (7-1/2 to 10 HP)
FIG:clrnc_rqrd
Side
VFD
3.7 kW (5 HP) or Less
C
A
A
Front
VFD
VFD
B
B
B
A
A
A
A
Side
Front
VFD
VFD
VFD
A
A
A
A
A
A
B
B
B
C
