Johnson Controls RHP150 Series User Manual

Table 5: 1.5 ton cooling charging chart for XA(F,H)*30C,
and JH(E,V)T*24C in downflow and horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
95 358 (4) 358 (4) 363 (4) 364 (4)
100 387 (4) 387 (4) 390 (4) 393 (4)
105 416 (4) 416 (4) 418 (4) 422 (4)
110 445 (4) 444 (5) 447 (5) 450 (4)
115 473 (4) 472 (5) 475 (5) 478 (4)
120 502 (5) 501 (5) 504 (5) 507 (5)
125 531 (5) 530 (5) 532 (5) 536 (5)
Table 6: 2 ton cooling charging chart for XAF*30C and
JH(E,V)T*24C in upflow
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 214 (12) 216 (12) 219 (11) 224 (11)
60 233 (12) 234 (12) 237 (12) 241 (12)
65 251 (12) 252 (12) 255 (12) 259 (12)
70 272 (13) 273 (13) 276 (12) 280 (12)
75 292 (13) 293 (13) 297 (13) 300 (13)
80 316 (14) 316 (14) 320 (14) 323 (13)
85 339 (14) 339 (15) 343 (14) 346 (14)
90 364 (15) 364 (15) 368 (15) 372 (14)
95 390 (15) 390 (16) 393 (15) 397 (14)
100 418 (15) 417 (15) 421 (15) 424 (14)
105 446 (15) 445 (15) 449 (15) 452 (14)
110 476 (15) 475 (15) 479 (15) 482 (14)
115 506 (14) 505 (15) 509 (14) 512 (13)
120 539 (14) 538 (15) 542 (14) 544 (13)
125 571 (14) 570 (15) 574 (15) 576 (13)
Table 7: 2 ton cooling charging chart for XAH*30C and
JH(E,V)T*24C in horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 218 (14) 220 (14) 223 (13) 228 (13)
60 237 (14) 238 (14) 242 (13) 246 (13)
65 256 (14) 257 (14) 260 (14) 264 (13)
Table 7: 2 ton cooling charging chart for XAH*30C and
JH(E,V)T*24C in horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
70 277 (14) 278 (15) 281 (14) 285 (14)
75 298 (15) 298 (15) 302 (15) 306 (15)
80 321 (16) 322 (16) 326 (16) 329 (15)
85 345 (17) 345 (17) 349 (16) 353 (16)
90 371 (17) 371 (17) 375 (17) 378 (16)
95 397 (18) 397 (18) 399 (16) 404 (17)
100 425 (17) 425 (18) 429 (17) 432 (16)
105 454 (17) 453 (18) 457 (17) 460 (16)
110 485 (17) 484 (17) 488 (17) 491 (16)
115 515 (16) 515 (17) 519 (16) 521 (15)
120 549 (16) 548 (17) 552 (17) 554 (15)
125 582 (16) 581 (17) 585 (17) 587 (15)
Table 8: 2 ton cooling charging chart for XA(F,H)*30C
and JH(E,V)T*24C in downflow and horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 209 (8) 211 (9) 214 (8) 219 (8)
60 227 (9) 228 (9) 232 (8) 236 (8)
65 245 (9) 246 (9) 249 (8) 253 (8)
70 265 (9) 266 (9) 270 (9) 273 (9)
75 286 (9) 286 (10) 290 (9) 293 (9)
80 308 (10) 309 (10) 312 (10) 316 (10)
85 331 (10) 331 (11) 335 (10) 338 (10)
90 356 (11) 356 (11) 359 (11) 363 (10)
95 381 (11) 380 (11) 382 (10) 387 (10)
100 408 (11) 408 (11) 411 (11) 414 (10)
105 435 (11) 435 (11) 438 (11) 441 (10)
110 465 (10) 464 (11) 468 (11) 471 (10)
115 494 (10) 494 (11) 497 (10) 500 (9)
120 526 (10) 525 (11) 529 (10) 531 (10)
125 558 (10) 557 (11) 561 (10) 563 (10)
Installation Manual: R-410A Outdoor Split-System Heat Pump - YH2F, THF2, RHP150 Series16
Johnson Controls Ducted Systems
