Johnson Controls RHP150 Series User Manual

Table 9: 2 ton cooling charging chart for
XA(F,H)*(30,36)D and JH(E,V)T*(30,36)D in upflow and
horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 219 (14) 220 (14) 223 (14) 228 (14)
60 237 (14) 239 (14) 242 (14) 246 (14)
65 256 (14) 257 (15) 261 (14) 264 (14)
70 277 (15) 278 (15) 282 (15) 285 (15)
75 298 (15) 299 (16) 303 (15) 306 (15)
80 322 (16) 323 (16) 326 (16) 330 (16)
85 346 (17) 346 (17) 350 (17) 353 (16)
90 372 (17) 372 (17) 376 (17) 379 (16)
95 398 (17) 398 (18) 401 (17) 405 (17)
100 426 (17) 426 (18) 430 (17) 433 (17)
105 455 (17) 454 (18) 458 (17) 461 (16)
110 486 (17) 485 (17) 489 (17) 492 (16)
115 516 (16) 516 (17) 520 (17) 522 (16)
120 550 (16) 549 (17) 553 (17) 555 (16)
125 583 (16) 582 (17) 586 (17) 588 (16)
Table 10: 2 ton cooling charging chart for
XA(F,H)*(30,36)D and JH(E,V)T*(30,36)D in downflow
and horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 216 (14) 217 (14) 221 (13) 225 (13)
60 234 (14) 236 (14) 239 (14) 243 (14)
65 253 (14) 254 (14) 257 (14) 261 (14)
70 274 (14) 275 (15) 278 (14) 282 (14)
75 295 (15) 295 (15) 299 (15) 303 (15)
80 318 (15) 318 (16) 322 (15) 326 (15)
85 341 (16) 342 (16) 345 (16) 349 (16)
90 367 (16) 367 (17) 371 (16) 374 (16)
95 393 (17) 393 (17) 395 (17) 400 (16)
100 421 (17) 421 (17) 424 (17) 428 (16)
105 449 (17) 449 (17) 452 (17) 456 (16)
110 479 (16) 479 (17) 483 (16) 486 (15)
115 510 (16) 509 (16) 513 (16) 516 (15)
120 543 (16) 542 (16) 546 (16) 548 (15)
125 576 (16) 575 (16) 579 (16) 581 (15)
Table 11: 2.5 ton cooling charging chart for
XAF*(30,36)D and JH(E,V)T*(30,36)D in upflow
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 206 (7) 209 (8) 212 (8) 216 (7)
60 224 (7) 227 (8) 229 (8) 233 (7)
65 241 (7) 244 (8) 247 (8) 251 (7)
70 261 (7) 264 (8) 267 (8) 271 (8)
75 281 (8) 284 (9) 287 (8) 291 (8)
80 304 (9) 306 (9) 309 (9) 313 (8)
85 327 (9) 329 (10) 332 (10) 335 (9)
90 352 (10) 354 (11) 357 (10) 360 (9)
95 378 (10) 379 (11) 382 (11) 385 (10)
100 405 (11) 407 (11) 409 (11) 413 (10)
105 433 (11) 435 (11) 437 (11) 440 (10)
110 464 (11) 465 (11) 467 (10) 470 (9)
115 494 (10) 495 (11) 497 (10) 500 (9)
120 527 (10) 528 (11) 530 (10) 532 (9)
125 560 (10) 561 (11) 563 (10) 565 (9)
Table 12: 2.5 ton cooling charging chart for XAH*36D
and JH(E,V)T*(30,36)D in horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 209 (9) 212 (10) 215 (9) 218 (9)
60 226 (9) 229 (10) 232 (9) 236 (9)
65 244 (9) 247 (10) 250 (9) 254 (9)
70 265 (9) 267 (10) 270 (10) 274 (9)
75 285 (10) 287 (11) 290 (10) 294 (10)
80 308 (11) 310 (11) 313 (11) 317 (10)
85 331 (11) 333 (12) 336 (12) 339 (11)
90 357 (12) 358 (13) 361 (12) 365 (12)
95 382 (13) 384 (14) 387 (13) 390 (12)
100 410 (13) 412 (14) 414 (13) 418 (12)
105 439 (13) 440 (14) 442 (13) 445 (12)
110 470 (13) 471 (14) 473 (13) 476 (11)
115 500 (13) 501 (14) 503 (13) 506 (11)
120 534 (13) 535 (14) 536 (13) 539 (11)
125 567 (13) 568 (14) 569 (13) 572 (11)
Installation Manual: R-410A Outdoor Split-System Heat Pump - YH2F, THF2, RHP150 Series 17
