Johnson Controls RHP150 Series User Manual

Table 13: 2.5 ton cooling charging chart for
XA(F,H)*(30,36)D and JH(E,V)T*(30,36)D in downflow
and horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 199 (3) 202 (4) 205 (4) 208 (4)
60 216 (3) 219 (4) 221 (4) 225 (3)
65 233 (3) 235 (4) 238 (4) 242 (3)
70 252 (4) 255 (4) 257 (4) 261 (4)
75 272 (4) 274 (4) 277 (4) 280 (4)
80 294 (4) 296 (4) 298 (4) 302 (4)
85 315 (4) 317 (5) 320 (5) 324 (4)
90 340 (5) 342 (5) 344 (5) 348 (4)
95 364 (5) 366 (5) 369 (5) 372 (5)
100 391 (5) 393 (5) 395 (5) 398 (5)
105 418 (5) 419 (5) 422 (5) 425 (5)
110 448 (5) 449 (5) 451 (5) 454 (4)
115 477 (5) 478 (5) 480 (5) 482 (4)
120 509 (5) 510 (5) 511 (5) 514 (4)
125 541 (5) 542 (5) 543 (5) 545 (4)
Table 14: 2.5 ton cooling charging chart for XAF*48F
and JH(E,V)T*42F in upflow
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 214 (12) 217 (13) 220 (13) 224 (13)
60 232 (12) 235 (13) 238 (13) 242 (12)
65 250 (12) 253 (13) 256 (13) 260 (12)
70 271 (13) 273 (13) 276 (13) 280 (13)
75 292 (13) 294 (14) 297 (13) 301 (13)
80 315 (14) 317 (14) 320 (14) 324 (14)
85 339 (14) 341 (15) 344 (15) 348 (14)
90 365 (15) 367 (16) 370 (15) 373 (14)
95 391 (16) 393 (16) 395 (16) 399 (15)
100 420 (16) 422 (16) 424 (16) 428 (15)
105 449 (16) 450 (17) 453 (16) 456 (15)
110 481 (16) 482 (16) 484 (16) 487 (14)
115 512 (15) 513 (16) 515 (15) 518 (14)
120 547 (16) 547 (16) 549 (15) 552 (14)
125 581 (16) 582 (16) 583 (16) 585 (14)
Table 15: 2.5 ton cooling charging chart for XAH*48F
and JH(E,V)T*42F in horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 218 (14) 221 (15) 224 (15) 228 (15)
60 236 (14) 239 (15) 242 (15) 246 (15)
65 255 (14) 258 (15) 261 (15) 265 (15)
70 276 (15) 279 (16) 282 (16) 286 (15)
75 297 (15) 300 (16) 303 (16) 307 (16)
80 321 (16) 323 (17) 326 (17) 330 (16)
85 345 (17) 347 (18) 350 (18) 354 (17)
90 372 (18) 374 (19) 376 (18) 380 (17)
95 399 (19) 400 (19) 403 (19) 407 (18)
100 428 (19) 429 (20) 432 (19) 436 (18)
105 458 (19) 459 (20) 461 (19) 465 (18)
110 490 (19) 491 (19) 493 (19) 496 (17)
115 522 (18) 523 (19) 525 (18) 528 (17)
120 557 (19) 558 (19) 559 (18) 562 (17)
125 592 (19) 593 (20) 594 (18) 596 (17)
Table 16: 2.5 ton cooling charging chart for
XA(F,H)*48F and JH(E,V)T*42F in downflow and
horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 204 (7) 207 (7) 210 (7) 214 (7)
60 221 (7) 224 (7) 227 (7) 231 (7)
65 239 (7) 241 (7) 244 (7) 248 (7)
70 258 (7) 261 (8) 264 (8) 268 (7)
75 278 (8) 281 (8) 283 (8) 287 (8)
80 301 (8) 303 (8) 306 (8) 309 (8)
85 323 (8) 325 (9) 328 (9) 332 (8)
90 348 (9) 350 (9) 353 (9) 356 (8)
95 373 (9) 375 (9) 377 (9) 381 (9)
100 401 (9) 402 (9) 405 (9) 408 (9)
105 429 (9) 430 (10) 432 (9) 435 (9)
110 459 (9) 460 (9) 462 (9) 465 (8)
115 489 (9) 490 (9) 492 (9) 494 (8)
120 522 (9) 522 (9) 524 (9) 526 (8)
125 554 (9) 555 (9) 556 (9) 559 (8)
Installation Manual: R-410A Outdoor Split-System Heat Pump - YH2F, THF2, RHP150 Series18
