Johnson Controls RHP150 Series User Manual

Table 17: 3 ton cooling charging chart for
XA(F,H)*(30,36)D and JH(E,V)T*(30,36)D in upflow and
horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 195 (5) 197 (6) 198 (5) 201 (5)
60 212 (4) 213 (6) 215 (5) 217 (4)
65 229 (4) 230 (5) 232 (5) 234 (4)
70 248 (4) 249 (6) 251 (5) 253 (4)
75 267 (5) 268 (6) 270 (5) 272 (5)
80 289 (5) 290 (6) 292 (6) 294 (5)
85 311 (6) 311 (7) 313 (6) 315 (5)
90 335 (6) 335 (7) 337 (7) 339 (6)
95 359 (6) 359 (8) 360 (7) 362 (6)
100 386 (7) 386 (8) 386 (7) 388 (6)
105 412 (7) 412 (8) 412 (7) 414 (6)
110 441 (6) 441 (8) 441 (7) 442 (6)
115 470 (6) 469 (7) 469 (7) 471 (5)
120 501 (5) 501 (7) 500 (6) 501 (5)
125 533 (5) 532 (7) 530 (6) 532 (5)
Table 18: 3 ton cooling charging chart for
XA(F,H)*(30,36)D and JH(E,V)T*(30,36)D in downflow
and horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 191 (3) 193 (4) 195 (4) 197 (3)
60 208 (3) 210 (4) 211 (3) 214 (3)
65 225 (3) 226 (4) 228 (3) 230 (3)
70 244 (3) 245 (4) 247 (4) 249 (3)
75 263 (3) 264 (4) 266 (4) 268 (3)
80 284 (4) 285 (4) 287 (4) 289 (4)
85 305 (4) 306 (5) 308 (4) 310 (4)
90 329 (4) 330 (5) 331 (5) 333 (4)
95 353 (5) 353 (6) 355 (5) 356 (4)
100 379 (5) 379 (6) 380 (5) 382 (4)
105 405 (5) 405 (6) 405 (5) 407 (4)
110 434 (4) 433 (6) 433 (5) 435 (4)
115 462 (4) 461 (5) 461 (5) 463 (4)
120 493 (4) 492 (5) 491 (5) 493 (4)
125 524 (4) 523 (5) 521 (4) 523 (3)
Table 19: 3 ton cooling charging chart for XA(F,H)*48F
and JH(E,V)T*42F in upflow and horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 198 (9) 200 (10) 202 (9) 205 (8)
60 216 (8) 217 (9) 219 (9) 222 (8)
65 233 (8) 235 (9) 236 (8) 239 (8)
70 253 (8) 254 (9) 256 (9) 258 (8)
75 272 (8) 273 (10) 275 (9) 277 (8)
80 294 (9) 295 (10) 297 (9) 299 (9)
85 317 (9) 317 (11) 319 (10) 321 (9)
90 341 (10) 342 (11) 343 (10) 345 (10)
95 366 (10) 366 (12) 367 (11) 369 (10)
100 393 (10) 393 (12) 394 (11) 396 (10)
105 420 (10) 420 (12) 420 (11) 422 (10)
110 449 (10) 449 (12) 449 (11) 451 (10)
115 479 (10) 478 (11) 478 (11) 480 (9)
120 511 (9) 510 (11) 509 (10) 511 (9)
125 543 (9) 542 (10) 540 (10) 542 (8)
Table 20: 3 ton cooling charging chart for XA(F,H)*48F
and JH(E,V)T*42F in downflow and horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 191 (4) 193 (5) 195 (4) 198 (4)
60 208 (4) 210 (5) 211 (4) 214 (4)
65 225 (4) 226 (5) 228 (4) 230 (4)
70 244 (4) 245 (5) 247 (4) 249 (4)
75 263 (4) 264 (5) 266 (5) 268 (4)
80 284 (5) 285 (5) 287 (5) 289 (4)
85 305 (5) 306 (5) 308 (5) 310 (5)
90 329 (5) 330 (6) 331 (5) 333 (5)
95 353 (5) 353 (6) 354 (6) 356 (5)
100 379 (5) 379 (6) 380 (6) 382 (5)
105 405 (5) 405 (6) 405 (6) 407 (5)
110 434 (5) 433 (6) 433 (6) 435 (5)
115 462 (5) 462 (6) 461 (5) 463 (5)
120 493 (5) 492 (6) 491 (5) 493 (5)
125 524 (5) 523 (5) 521 (5) 523 (4)
Installation Manual: R-410A Outdoor Split-System Heat Pump - YH2F, THF2, RHP150 Series 19
