Johnson Controls RHP150 Series User Manual

Table 21: 3.5 ton cooling charging chart for
XA(F,H)*48F and JH(E,V)T*42F in upflow and horizontal
left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 204 (7) 207 (7) 208 (7) 212 (7)
60 221 (7) 224 (7) 226 (7) 230 (7)
65 239 (7) 241 (7) 244 (7) 247 (7)
70 259 (7) 261 (8) 264 (8) 268 (8)
75 279 (8) 281 (8) 284 (8) 288 (8)
80 301 (9) 304 (9) 307 (9) 311 (9)
85 324 (9) 326 (10) 330 (10) 334 (10)
90 349 (10) 352 (10) 355 (10) 359 (10)
95 374 (10) 377 (11) 380 (11) 384 (11)
100 402 (10) 404 (11) 408 (11) 412 (10)
105 430 (11) 432 (11) 436 (11) 439 (10)
110 461 (10) 463 (11) 466 (11) 470 (10)
115 491 (10) 493 (11) 497 (10) 500 (10)
120 524 (10) 526 (11) 530 (11) 532 (10)
125 558 (10) 559 (11) 563 (11) 565 (10)
Table 22: 3.5 ton cooling charging chart for
XA(F,H)*48F and JH(E,V)T*42F in downflow and
horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 202 (5) 204 (5) 206 (5) 210 (5)
60 219 (5) 222 (5) 224 (5) 227 (5)
65 236 (5) 239 (5) 241 (5) 245 (5)
70 256 (5) 258 (6) 261 (6) 265 (6)
75 275 (6) 278 (6) 281 (6) 285 (6)
80 298 (6) 300 (7) 304 (7) 307 (7)
85 320 (7) 323 (7) 326 (7) 330 (7)
90 345 (7) 348 (8) 351 (7) 355 (7)
95 370 (8) 373 (8) 376 (8) 380 (8)
100 398 (8) 400 (8) 404 (8) 407 (8)
105 425 (8) 427 (8) 431 (8) 435 (8)
110 456 (8) 457 (8) 461 (8) 464 (8)
115 486 (7) 487 (8) 491 (8) 494 (7)
120 519 (8) 520 (8) 524 (8) 526 (7)
125 551 (8) 553 (8) 556 (8) 559 (8)
Table 23: 3.5 ton cooling charging chart for XAF*60G
and JH(E,V)T*48G in upflow
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 204 (8) 207 (8) 209 (8) 213 (8)
60 222 (8) 224 (8) 226 (8) 230 (8)
65 239 (8) 242 (8) 244 (8) 248 (8)
70 259 (8) 262 (9) 264 (8) 268 (8)
75 279 (9) 282 (9) 285 (9) 288 (9)
80 302 (9) 304 (10) 307 (10) 311 (10)
85 324 (10) 327 (10) 330 (10) 334 (10)
90 350 (11) 352 (11) 355 (11) 359 (11)
95 375 (11) 377 (12) 381 (11) 385 (11)
100 403 (11) 405 (12) 409 (12) 412 (11)
105 431 (11) 433 (12) 437 (12) 440 (11)
110 461 (11) 463 (12) 467 (11) 470 (11)
115 492 (11) 494 (11) 497 (11) 500 (11)
120 525 (11) 527 (12) 530 (11) 533 (11)
125 558 (11) 560 (12) 563 (12) 566 (11)
Table 24: 3.5 ton cooling charging chart for XAH*60G
and JH(E,V)T*48G in horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 215 (12) 218 (12) 220 (11) 224 (11)
60 233 (11) 236 (12) 238 (11) 242 (12)
65 251 (11) 254 (12) 257 (12) 261 (12)
70 272 (12) 275 (13) 278 (12) 282 (13)
75 293 (13) 296 (13) 299 (13) 303 (13)
80 317 (14) 320 (14) 323 (14) 327 (14)
85 341 (15) 344 (16) 347 (15) 351 (15)
90 368 (16) 370 (16) 374 (16) 378 (16)
95 394 (16) 397 (17) 401 (17) 405 (17)
100 424 (17) 426 (17) 430 (17) 434 (17)
105 453 (17) 455 (18) 459 (17) 463 (17)
110 485 (16) 487 (17) 491 (17) 495 (16)
115 517 (16) 519 (17) 523 (16) 526 (16)
120 552 (16) 554 (17) 558 (17) 561 (16)
125 587 (16) 589 (17) 593 (17) 595 (16)
Installation Manual: R-410A Outdoor Split-System Heat Pump - YH2F, THF2, RHP150 Series20
Johnson Controls Ducted Systems
