Table 33: 5 ton cooling charging chart for XAH*60H and
JH(E,V)T*60H in horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 209 (12) 215 (13) 213 (13) 213 (13)
60 229 (12) 234 (12) 233 (13) 233 (13)
65 248 (12) 253 (12) 253 (13) 254 (13)
70 267 (12) 271 (12) 273 (12) 274 (13)
75 286 (12) 290 (12) 293 (12) 295 (13)
80 311 (12) 314 (12) 316 (12) 319 (13)
85 336 (12) 338 (12) 340 (12) 344 (13)
90 361 (12) 362 (12) 364 (12) 367 (13)
95 387 (12) 386 (12) 388 (12) 391 (13)
100 417 (12) 417 (12) 419 (12) 423 (13)
105 448 (12) 448 (12) 450 (12) 454 (13)
110 478 (12) 478 (12) 481 (12) 485 (13)
115 508 (12) 509 (12) 512 (12) 516 (13)
120 539 (12) 540 (12) 543 (12) 547 (12)
125 569 (12) 571 (12) 574 (12) 579 (12)
Table 34: 5 ton cooling charging chart for XAH*60J and
JH(E,V)T*60J in horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 197 (12) 202 (13) 201 (13) 201 (13)
60 215 (12) 220 (13) 219 (13) 220 (13)
65 233 (12) 237 (12) 237 (13) 238 (13)
70 251 (12) 255 (12) 256 (13) 258 (13)
75 269 (12) 273 (12) 275 (12) 277 (13)
80 292 (12) 295 (12) 298 (12) 300 (13)
85 316 (12) 318 (12) 320 (12) 323 (13)
90 340 (12) 340 (12) 342 (12) 345 (13)
95 364 (12) 363 (12) 365 (12) 368 (13)
100 392 (12) 392 (12) 394 (12) 397 (13)
105 421 (12) 421 (12) 423 (12) 427 (13)
110 449 (12) 450 (12) 452 (12) 456 (13)
115 478 (12) 479 (12) 481 (12) 485 (13)
120 506 (12) 508 (12) 510 (12) 515 (13)
125 535 (12) 537 (12) 540 (12) 544 (12)
Installation Manual: R-410A Outdoor Split-System Heat Pump - YH2F, THF2, RHP150 Series 23
Johnson Controls Ducted Systems
