Johnson Controls Sabroe SAB 233 S - Sab 193 S; Sab 193 L

Engineering manual - SAB 193-233-283 S A-frame (including ATEX)
008831 en 2020.10
113/168
Installation instructions
Motor displacement Compressor
Column
1
Column
2
Column
3
Column
4
Column
5
Column
6
Centre of gravity on unit
Column
7
Column
8
Column
9
x
flange
Yg
motor
zg
motor
Shaft
height
∆z
zi
∑M
comp
X Y
z
SAB 120 1031 500 1222 137 203 488 1562 414
1288
(IEC250)
SAB 151 794 607 1242 157 220 658 1522 481
1305
(IEC250)
SAB 193 S 1217 377 1323 290 310 1081 2053 463 1343
SAB 193 L 1217 377 1323 290 325 1206 2080 457 1358
SABflex 927 421 1284 394 413 660 1630 427 1303
Fixed values
Calculated and/or edited values
Table 29
∑M comp = comp + tunnel+ support + POV + stop valve
zi: centre of gravity of compressor in relation to dist. flange
zg motor = h + Shaft height ∆z + J
z = h + zi + J
Shaft height ∆z: dist. discharge flanges (∆z) to drive shaft
j: height of discharge flange (from dimension sketch)
SABflex j: 0
zi from Table 29, Column 5
h from Table 28
Example: SAB 193 L, J = 143 gives
zg motor = 890 + 290 + 143
z = 890 + 325 + 143
Oil filter, Oil cooler, Oil pump
Type
M
x
y
z
Oil cooler
AlfaNova
ANHP52-1 63 1720 -172 422
Wahterus
3HH 34 134.4 1659 -147 385
3HH 66 159.6 1659 -147 385
3 HH 116 207.6 1659 -147 385
Oil pump
960A0082
65 2440 133 450
Oil filter 1,
lower
SAB 193 535E0013EU 126 256 -147 210
Oil filter 2,
upper
SAB 193 126 256 -147 605
Oil filter 1,
lower
SAB 151/
SABflex
535C0513 39.6 500 -147 330
Oil filter 2,
upper
SAB 151/
SABflex
39.6 500 -147 660
Fixed values
Calculated and/or edited values
Table 30
The parts have been added weight for estimated related tubing, oil, etc.
