T500 Series Programmable Thermostats Product/Technical Bulletin
3
!
CAUTION:
Equipment Damage Hazard.
Before applying power, make all
wiring connections and check
the connections. Short-circuited
or improperly connected wires
may result in permanent
damage to the unit.
Figure 3: Separating the T500 from the Base
Figure 4: Mounting the Base
