Johnson Controls T60xDFH-4 User Manual

T60xDFH-4 and T60xDFH-4+PIR Series Thermostat Controllers with Dehumidification and Occupancy
Sensing Capability Installation Instructions
11
Table 2: Selection Options for Sequence of Operation in Two-Pipe Applications
Selection
Option
Control
Curve
Terminal Numbers Used (See Table 1 and Figure 5.)
On/Off Control Floating Control Proportional
0to10VDC Control
(0): Cooling Only See Figure 14. 10: Normally Open
(N.O.) Cooling
11: Normally Closed
(N.C.) Cooling
10: Open Cooling
11: Closed Cooling
10: Proportional Cooling
(1): Heating Only See Figure 15. 10: N.O. Heating
11: N.C. Heating
10: Open Heating
11: Closed Heating
10: Proportional Heating
(2): Cooling and Reheat See Figure 16. 6 and 7: Reheat
10: N.O. Cooling
11: N.C. Cooling
6 and 7: Reheat
10: Open Cooling
11: Closed Cooling
6 and 7: Reheat
10: Proportional Cooling
(3): Heating and Reheat See Figure 17. 6 and 7: Reheat
10: N.O. Heating
11: N.C. Heating
6 and 7: Reheat
10: Open Heating
11: Closed Heating
6 and 7: Reheat
10: Proportional Heating
Table 3: Selection Options for Sequence of Operation in Four-Pipe Applications
Selection
Option
Control
Curve
Terminal Numbers Used (See Table 1 and Figure 5.)
On/Off Control Floating Control Proportional
0to10VDC Control
(0): Cooling Only See Figure 14. 10: N.O. Cooling
11: N.C. Cooling
10: Open Cooling
11: Closed Cooling
10: Proportional Cooling
(1): Heating Only See Figure 15. 8: N.O. Heating
9: N.C. Heating
8: Open Heating
9: Closed Heating
9: Proportional Heating
(2): Cooling and Reheat See Figure 16. 6 and 7: Reheat
10: N.O. Cooling
11: N.C. Cooling
6 and 7: Reheat
10: Open Cooling
11: Closed Cooling
6 and 7: Reheat
10: Proportional Cooling
(3): Heating and Reheat See Figure 17. 6 and 7: Reheat
8: N.O. Heating
9: N.C. Heating
6 and 7: Reheat
8: Open Heating
9: Closed Heating
6 and 7: Reheat
9: Proportional Heating
(4): Cool/Heat Four-Pipe See Figure 18. 8: N.O. Heating
9: N.C. Heating
10: N.O. Cooling
11: N.C. Cooling
8: Open Heating
9: Closed Heating
10: Open Cooling
11: Closed Cooling
9: Proportional Heating
10: Proportional Cooling
(5): Cool/Heat Four-Pipe
and Reheat
See Figure 19. 6 and 7: Reheat
8: N.O. Heating
9: N.C. Heating
10: N.O. Cooling
11: N.C. Cooling
6 and 7: Reheat
8: Open Heating
9: Closed Heating
10: Open Cooling
11: Closed Cooling
6 and 7: Reheat
9: Proportional Heating
10: Proportional Cooling
