Johnson Controls TEC2216H-4 User Manual

TEC22x6(H)-4 and TEC22x6H-4+PIR Series LONWORKS® Network Thermostat Controllers with
Dehumidification Capability, Fan Control, and Occupancy Sensing Capability Installation Instructions
18
DehuHyst Sets the dehumidification hysteresis
(TEC2236-4, TEC2236H-4,
TEC2236H-4+PIR, TEC2256-4,
TEC2256H-4, and
TEC2256H-4+PIR models). This
parameter can only be used if
dehumidification sequence is
enabled.
Default: 5.0% RH
Range: 2.0 to 20.0% RH
DehuCool Sets the maximum dehumidification
cooling output (TEC2236-4,
TEC2236H-4, TEC2236H-4+PIR,
TEC2256-4, TEC2256H-4, and
TEC2256H-4+PIR models). This
parameter can only be used if
dehumidification sequence is
enabled.
Default: 100.0%
Range: 20.0 to 100.0%.
Note: This parameter can be used to balance smaller reheat loads
installed with regard to the capacity of the cooling coil.
St-By TM Sets stand-by timer value when
used with occupancy sensor; time
delay between moment where
occupancy sensor detected the last
movement in the area and the time
which the thermostat stand-by mode
and setpoints become active.
Default: 0.5 hours
Range: 0.5 to 24.0 hours, in 0.5 hour increments
Unocc TM Sets Unoccupied Timer Value when
used with occupancy sensor; time
delay between the moment where
the thermostat toggles to stand-by
mode and the time which the
thermostat unoccupied mode and
setpoints become active.
Default: 0.0 hours
0.0 hours or Factory Value: Setting this parameter to its default 0
value disables the occupied timer and prevents the thermostat from
drifting from stand-by mode to unoccupied mode when occupancy
sensor functions are used.
Range: 0.0 to 24.0 hours in 0.5 hour increments
Table 5: Installer Configuration Menu (Part 4 of 8)
Parameter
Appearing
on Display
Description and Default Selection Options
