Johnson Controls TEC2216H-4 User Manual

TEC22x6(H)-4 and TEC22x6H-4+PIR Series LONWORKS® Network Thermostat Controllers with
Dehumidification Capability, Fan Control, and Occupancy Sensing Capability Installation Instructions
19
St-By HT Sets Stand-by heating setpoint
when used with occupancy sensor;
value is between occupied and
unoccupied heating setpoints.
Default: 69.0°F/20.6°C
Range: 40.0°F/4.5°C to
90.0°F/32.0°C
Note: When adjusting the
temperature, press the
UP/DOWN arrow keys to
change the temperature in
0.5F°/0.5C° increments; press
and hold the UP/DOWN arrow
keys to change the
temperature in 5.0F°/5.0C°
increments.
St-By CL Sets Stand-by cooling setpoint limit
when used with occupancy sensor;
value is between occupied and
unoccupied cooling setpoints.
Default: 78.0°F/25.6°C
Range: 54.0°F/12.0°C to
100.0°F/37.5°C
Unocc HT Sets the Unoccupied Heating
setpoint value.
Default: 62.0°F/16.5°C
Range: 40.0°F/4.5°C to
90.0°F/32.0°C
Unocc CL Sets the Unoccupied Cooling
setpoint value.
Default: 80.0°F/26.5°C
Range: 54.0°F/12.0°C to
100°F/37.5°C
Heat max Sets the Occupied and Unoccupied
maximum Heating setpoint values.
Default: 90.0°F/32.0°C
Range: 40.0°F/4.5°C to
90.0°F/32.0°C
Cool min Sets the Occupied and Unoccupied
minimum Cooling setpoint values.
Default: 54.0°F/12.0°C
Range: 54.0°F/12.0°C to
100°F/37.5°C
Pband Proportional Band used by the PI
temperature control loop of the
thermostat.
Pband is not converted with C or F
scale and is always shown with a
range of 3 to 10.
Default: 3 (3F°/1.7C°)
Value F Scale Pband/C Scale Pband
3 3.0F°/1.7C°
4 4.0F°/2.2C°
5 5.0F°/2.8C°
6 6.0F°/3.3C°
7 7.0F°/3.9C°
8 8.0F°/4.4C°
9 9.0F°/5.0C°
10 10.0F°/5.6C°
Note: The use of a larger proportional band is not to use the
thermostat as a discharge air controller device. The use of a larger
proportional band can be used to solve issues for flawed HVAC
design with basic sizing and thermostat location errors that cannot
be worked around.
Set type Provides the option of temporarily
changing the heating or cooling
setpoint by pressing the UP/DOWN
arrow keys.
Default: permnent
(temporar): Local changes to the heating or cooling setpoints are
temporary, and remain effective for the specified TOccTime.
(permnent): Local changes to the heating or cooling setpoints are
permanently stored in the thermostat memory.
Table 5: Installer Configuration Menu (Part 5 of 8)
Parameter
Appearing
on Display
Description and Default Selection Options
