Johnson Controls TEC2216H-4 User Manual

TEC22x6(H)-4 and TEC22x6H-4+PIR Series LONWORKS® Network Thermostat Controllers with
Dehumidification Capability, Fan Control, and Occupancy Sensing Capability Installation Instructions
20
Spt Func Determines the operation and
usage of the local setpoint interface
by the user.
Default: Dual Stp
(Attch Stp): Single Occupied Setpoint Adjustment. The displayed
setpoint is the setpoint from the last action taken by the thermostat
controller, or the setpoint currently in use. Both the heating and
cooling setpoints are changed simultaneously, while respecting the
minimum configured deadband. If one setpoint is desired over the
other, use the MODE key to toggle between the two setpoints.
(Dual Stp): Dual Occupied Setpoint Adjustment. The displayed
setpoint is the setpoint from the last action taken by the thermostat
controller, or the setpoint currently in use. The heating and cooling
setpoints can be separated individually, allowing the minimum
configured deadband to expand. If one setpoint is desired over the
other, use the MODE key to toggle between the two setpoints.
TOccTime Sets the duration of the Temporary
Occupancy Time when the
thermostat controller is in the
Unoccupied mode and a Schedule
Override Function is enabled using
either the Main User Menu or BI1, or
BI2 is configured as a temporary
override remote contact (RemOVR).
Sets the effective duration of the
Temporary heating or cooling
setpoints using the UP/DOWN
arrow keys.
Default: 2.0 hrs
Range: 0.0 to 24.0 hrs in 1-hour increments
Deadband Sets the minimum deadband
between the heating and cooling
setpoints.
Default: 2.0F°/1.0C°
Range: 2.0F°/1.0C° to 5.0F°/2.5C° (adjustable in 1.0F°/0.5C°
increments)
Cal RS Sets the desired room air sensor
calibration (offset). The offset can
be added to or subtracted from the
actual displayed room temperature.
Default: 0.0F°/0.0C°
Range: -5.0F°/-2.5C° to 5.0F°/2.5C° (adjustable in 1.0F°/0.5C°
increments)
Cal RH Sets the desired humidity sensor
calibration (offset). The offset can
be added to or subtracted from the
actual displayed room humidity
(TEC2236-4, TEC2236H-4,
TEC2236H-4+PIR, TEC2256-4,
TEC2256H-4, and
TEC2256H-4+PIR models). This
parameter can be used only if the
dehumidification sequence is
enabled.
Default: 0% RH
Range: -15.0% RH to 15.0% RH (adjustable in 1% RH increments)
Table 5: Installer Configuration Menu (Part 6 of 8)
Parameter
Appearing
on Display
Description and Default Selection Options
