TEC26x7-2 Series BACnet® MS/TP Networked Thermostats with Two Outputs Installation Instructions10
Cooling (BO1 and BO2) Valve Status
(TEC2627-2 Model)
5
MSV 67 For On/Off Control:
1 = Open
2 = Closed
For Floating Control:
1 = Stopped
2 = Opening
3=Closing
BI1 Status
5, 6
BI 62 0 = Deactivated
1 = Activated
BI2 Status
5, 6
BI 63 0 = Deactivated
1 = Activated
UI3 Status
5, 6
BI 64 0 = Deactivated
1 = Activated
Window Alarm
5
BI 58 0 = Off
1=On
Filter Alarm
5
BI 59 0 = Off
1=On
Service Alarm
5
BI 60 0 = Off
1=On
Occupied Heat Setpoint
3, 7
AV 49 40.0°F/4.5°C to
90.0°F/32.0°C
Occupied Cool Setpoint
3, 7
AV 50 54.0°F/12.0°C to
100.0°F/37.5°C
Unoccupied Heat Setpoint
3, 7
AV 51 40.0°F/4.5°C to
90.0°F/32.0°C
Unoccupied Cool Setpoint
3, 7
AV 52 54.0°F/12.0°C to
100.0°F/37.5°C
Keypad Lockout
3
MSV 40 1 = Level 0
2=Level1
3=Level2
4=Level3
5=Level4
6=Level5
BI1 Configuration
3
MSV 16 1 = None
2=RemNSB
3=MotionNO
4=MotionNC
5 = Window
BI2 Configuration
3
MSV 17 1 = None
2 = Door Dry
3 = Override
4 = Filter
5=Service
UI3 Configuration
3
MSV 18 1 = None
2 = COC/NH
3 = COC/NC
4=COS
5=SS
Menu Scroll
3
BV 19 0 = No Scroll
1=ScrollActive
Temperature Scale
3
BV 21 0 = °C
1=°F
Table 2: MS/TP Bus Objects (Part 2 of 4)
Point Name Thermostat Point
(Type/Address)
Range
