TEC26x7-2 Series BACnet® MS/TP Networked Thermostats with Two Outputs Installation Instructions 11
Out 1 (BO1 and BO2) Configuration
3
MSV 23 1 = False
2=True
AUX (BO5) Configuration
3
MSV 24 1 = Not Used
2=NOwithOcc
3 = NC with Occ
6 = Network Controlled
Heating Setpoint Limit
3
AV 27 40.0°F/4.5°C to
90.0°F/32.0°C
Cooling Setpoint Limit
3
AV 28 54.0°F/12.0°C to
100.0°F/37.5°C
Setpoint Type
3
BV 29 0 = Permanent
1 = Temporary
Temporary Occupancy Time
3
MSV 30 1 = 0 Hours
2=1Hour
3=2Hours
4=3Hours
5=4Hours
6=5Hours
7=6Hours
8=7Hours
9=8Hours
10 = 9 Hours
11 = 10 Hours
12 = 11 Hours
13 = 12 Hours
14 = 13 Hours
15 = 14 Hours
16 = 15 Hours
17 = 16 Hours
18 = 17 Hours
19 = 18 Hours
20 = 19 Hours
21 = 20 Hours
22 = 21 Hours
23 = 22 Hours
24 = 23 Hours
25 = 24 Hours
Door Time
3
MSV 31 1 = 1 Minute
2=2Minutes
3=3Minutes
4=4Minutes
5=5Minutes
6=6Minutes
7=7Minutes
8=8Minutes
9=9Minutes
10 = 10 Minutes
Deadband
3
AV 32 2F°/1C° to
5F°/2.5C°
Reheat Time Base (BO5)
3
BV 33 0 = 15 Minutes
1 = 10 Seconds
Control Type (TEC2627-2 Model)
3
BV 35 0 = On/Off
1 = Floating
Table 2: MS/TP Bus Objects (Part 3 of 4)
Point Name Thermostat Point
(Type/Address)
Range
