Position transmitter for new SAB (RWF) compressors
Description SAB 193 SAB 233 SAB 283 SAB 355
Capacity
transmitters
Aluminium
tube for LS
534D1251H02 534D1251H02 534D1251H02 534D1251H02
Linear trans-
mitter (2) LS
534D1251H03 534D1251H03 534D1251H03 534D1251H03
Volume trans-
mitters
Indicator rod
for SS
534C1314H01 534C1314H01 534C1314H02 534C1314H03
Linear trans-
mitter (1) SS
534C1478H02 534C1478H02 534C1478H02 534C1478H02
(1) Short stroke, without well.
Short stroke linear transmitter assembly, with well: 534C1478H01.
(2) Long stroke, without well.
Long stroke linear transmitter assembly, with well: 534D1251H01.
Position transmitter for new SAB (XJS, SJF) compressors
Description SAB 120 SAB 151
Indicator rod for SS 534B0987H01 534B0872H01
Linear transmitter (3) SS 534C1552H02 534C1552H02
(3) Short stroke, without well.
Short stroke linear transmitter assembly, with well: 534C1552H01.
Operating Unisab III control
48/48
Operating manual - Unisab III
005650-en 2013.10
