Johnson Controls VMA1630 Installation Instructions

Table 2: Termination Details
Termination DiagramsType of
Input/Output
Type of Field
Device
UIDry Contact
CO0–10 VDC Output to
Actuator (External
Source)
CO0–10 VDC Output to
Actuator (Internal
Source)
Note: Applies to CO4 and CO5.
CO24 VAC Triac
Output (Switch
Low, External
Source)
Note: Applies to CO4 and CO5.
COIncremental Control
to Actuator (Switch
Low, External
Source)
COAnalog Output
(Voltage)
10VMA1615/1626/1628/1630 VAV Controllers Installation Instructions
