Table 9: VMA Controller Status LEDs
Descriptions of LED StatesNormal StateLED ColorLED Label
Off Steady = No power
On Steady = Power is supplied by primary voltage
On SteadyGreenPOWER
Blink - 2 Hz = Download or startup in progress, not ready for normal
operation, SA Bus devices offline (such as netsensors)
Rapid blink = SA Bus communications issue
Off Steady = No faults
On Steady = Device fault or no application loaded
Off SteadyRedFAULT
Blink - 2 Hz = Data transmission (normal communication)
Off Steady = No data transmission (auto baud in progress)
On Steady = communication lost, waiting to join communication
ring
Blink - 2 HzGreenFC BUS
Blink - 2 Hz = Data transmission (normal communication)
Off Steady = No data transmission (N/A - auto baud not supported)
On Steady = Communication lost; waiting to join communication
ring
Blink - 2 HzGreenSA BUS
On Steady = EOL is active
Off Steady = EOL is not active
OffAmberEOL
Accessories
Use Table 10 to order accessories.
Table 10: VMA1615/1626/1628/1630 Controller Accessories (Order Separately)
DescriptionProduct Code Number
Refer to the Metasys® System Field Equipment Controllers and Related Products Product Bulletin
(LIT-12011042) for a complete list of available IOM Series Controllers.
IOM Series Controllers
Refer to the Mobile Access Portal Gateway Catalog Page (LIT-1900869) to identify the appropriate
product for your region.
Mobile Access Portal
(MAP) Gateway
Local Controller DisplayMS-DIS1710-0
Cable Replacement Set for the MS-BTCVT-1 or the NS-ATV7003-0; includes One 1.5 m (5 ft)
Retractable Cable
MS-BTCVTCBL-700
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 92 VA, Foot Mount, 72.2 cm (30
in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y64T15-0
Transformer, 120 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount (Y65AS), 20.32 cm (8
in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65A13-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Hub Mount (Y65SP+),
20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
Y65T42-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount (Y65AR+),
20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
Y65T31-0
2-position Screw Terminal that plugs onto VMA Output Point Spade LugsAP-TBK1002-0
3-position Screw Terminal that plugs onto VMA Output Point Spade LugsAP-TBK1003-0
Replacement MS/TP SA Bus Terminal, 4-Position Connector, Brown, Bulk Pack of 10AP-TBK4SA-0
Replacement MS/TP FC Bus Terminal, 4-Position Connector, Blue, Bulk Pack of 10AP-TBK4FC-0
Replacement Power Terminal, 2-Position Connector, Gray, Bulk Pack of 10AP-TBK2PW-0
20VMA1615/1626/1628/1630 VAV Controllers Installation Instructions
