LITERATURE SUPPLEMENT
File with: 150.62-NM6 (103)
Form Number:
150.62-NM6 (LS01)
603
Supercedes: None
Subject: Added YCAL0134 Model, Updated Electrical Data, Physical Data, and Isolator
Selection
TABLE 2 – SINGLE-POINT POWER SUPPLY
SINGLE-POINT POWER SUPPLY CONNECTIONS – YCAL0014E_ - YCAL0034E_
(One Field Provided Power Supply to the chiller. Field connections to Factory Provided Power Terminal Block (standard), Non-Fused Discon-
nect Switch (optional) or Circuit Breaker (optional).)
MODEL
YCAL
VOLT HZ
SINGLE POINT FIELD SUPPLIED WIRING SYSTEM #1 COMPRESSOR & FAN
MCA
1
MIN
N/F
DISC
SW
2
D.E. FUSE CKT. BKR.
5
INCOMING (LUGS) WIRE RANGE
6
COMPR. #1 COMPR. #2 COMPR. #3 FANS
TERMINAL
BLOCK
(std)
NF DISC.
SWITCH
(opt)
CIRCUIT
BREAKER
(opt)MIN
3
MAX
4
MIN MAX RLA LRA RLA LRA RLA LRA QTY FLA(EA)
0014
200 60 81 100 90 100 90 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 28.3 189 28.3 189 — — 2 8.2
230 60 75 100 90 100 90 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 26.2 189 26.2 189 — — 2 7.8
380 60 44 60 50 50 50 50 # 10 - # 1 # 14 - 1/0 # 14 - 2 15.1 112 15.1 112 — — 2 4.8
460 60 37 60 40 45 40 45 # 10 - # 1 # 14 - 1/0 # 14 - 2 12.5 99 12.5 99 — — 2 4.0
575 60 29 60 35 35 35 35 # 10 - # 1 # 14 - 1/0 # 14 - 2 10.0 74 10.0 74 — — 2 3.1
0020
200 60 101 150 110 125 110 125 # 10 - # 1 # 14 - 1/0 # 2 - 4/0 37.4 278 37.4 278 — — 2 8.2
230 60 94 100 110 125 110 125 # 10 - # 1 # 14 - 1/0 # 2 - 4/0 34.6 278 34.6 278 — — 2 7.8
380 60 55 60 60 70 60 70 # 10 - # 1 # 14 - 1/0 # 14 - 2 19.9 151 19.9 151 — — 2 4.8
460 60 46 60 50 60 50 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 16.5 127 16.5 127 — — 2 4.0
575 60 36 60 40 45 40 45 # 10 - # 1 # 14 - 1/0 # 14 - 2 13.2 100 13.2 100 — — 2 3.1
0024
200 60 128 150 150 175 150 175 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 49.4 350 49.4 350 — — 2 8.2
230 60 119 150 150 150 150 150 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 45.8 350 45.8 350 — — 2 7.8
380 60 69 100 80 90 80 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 26.4 195 26.4 195 — — 2 4.8
460 60 58 60 70 70 70 70 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 21.8 158 21.8 158 — — 2 4.0
575 60 46 60 50 60 50 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 17.4 125 17.4 125 — — 2 3.1
0030
200 60 138 150 175 175 175 175 # 10 - 3/0 # 2 - 4/0 # 3 - 300 53.8 425 53.8 425 — — 2 8.2
230 60 128 150 150 175 150 175 # 10 - 3/0 # 2 - 4/0 # 3 - 300 49.8 425 49.8 425 — — 2 7.8
380 60 75 100 90 100 90 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 28.7 239 28.7 239 — —- 2 4.8
460 60 62 100 70 80 70 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 23.7 187 23.7 187 — — 2 4.0
575 60 49 60 60 60 60 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 19.0 148 19.0 148 — — 2 3.1
0034
200 60 178 200 200 225 200 225 # 10 - 300 # 3 - 300 # 3 - 300 49.4 350 49.4 350 49.4 350 2 8.2
230 60 165 200 200 200 200 200 # 10 - 300 # 3 - 300 # 3 - 300 45.8 350 45.8 350 45.8 350 2 7.8
380 60 96 150 110 110 110 110 # 10 - # 1 # 14 - 1/0 # 2 - 4/0 26.4 195 26.4 195 26.4 195 2 4.8
460 60 79 100 90 100 90 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 21.8 158 21.8 158 21.8 158 2 4.0
575 60 63 100 70 80 70 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 17.4 125 17.4 125 17.4 125 2 3.1
For YCAL0134 model wiring diagrams, refer to 150.62-NM6. Diagrams for YCAL0014-
YCAL0124 are also valid for YCAL0134.
