JOHNSON CONTROLS
30
FORM 150.62-NM6 (103)
OPERATIONAL LIMITATIONS (ENGLISH)
VOLTAGE LIMITATIONS
The following voltage limitations are absolute and
operation beyond these limitations may cause serious
damage to the compressor.
TABLE 8 – VOLTAGE LIMITATIONS
UNIT POWER MIN. MAX.
200-3-60 180 220
230-3-60 207 253
380-3-60 355 415
460-3-60 414 506
575-3-60 517 633
Installation
Excessive ow will cause damage to
the cooler. Do not exceed max. cooler
flow. Special care should be taken
when multiple chillers are fed by a
single pump.
TABLE 7 – TEMPERATURES AND FLOWS
NOTES:
1. For leaving brine temperature below 40°F (4.4°C), contact your nearest YORK Ofce for application requirements.
2. For leaving water temperature higher than 55°F (12.8°C), contact the nearest YORK Ofce for application guidelines.
3. The evaporator is protected against freezing to -20°F (-28.8°C) with an electric heater as standard.
4. For operation at temperatures below 25°F (-3.9°C), the optional Low Ambient Kit will need to be installed on the system (for YCAL0014-0080
models only).
5. For operation at temperatures above 115°F (46.1°C), the optional High Ambient Kit will need to be installed on the system.
YCAL
LEAVING WATER
TEMPERATURE (°F) COOLER FLOW (GPM
3
) AIR ON CONDENSER (°F)
MIN
1
MAX
2
MIN MAX MIN
4
MAX
5
0014 40 55 25 60 0 125
0020 40 55 25 60 0 125
0024 40 55 30 70 0 125
0030 40 55 35 170 0 125
0034 40 55 35 170 0 125
0040 40 55 60 325 0 125
0042 40 55 60 325 0 125
0044 40 55 60 325 0 125
0050 40 55 60 325 0 125
0060 40 55 60 325 0 125
0064 40 55 100 350 0 125
0070 40 55 100 350 0 125
0074 40 55 100 350 0 125
0080 40 55 100 400 0 125
0090 40 55 138 525 0 125
0094 40 55 138 525 0 125
0104 40 55 156 625 0 125
0114 40 55 156 625 0 125
0124 40 55 156 625 0 125
