Johnson Controls York YCAL0124E Series User Manual

JOHNSON CONTROLS
29
FORM 150.62-NM6 (103)
1
SYSTEM #1 COMPRESSOR & FAN SYSTEM #2 FIELD SUPPLIED WIRING
COMPR. #1 COMPR. #2 COMPR. #3 FANS COMPR. #1 COMPR. #2 COMPR. #3 FANS
RLA LRA RLA LRA RLA LRA QTY FLA(EA) RLA LRA RLA LRA RLA LRA QTY FLA(EA)
100.2 550 100.2 550 — — 3 8.2 73.9 450 73.9 450 — — 3 8.2
92.8 550 92.8 550 — — 3 7.8 68.5 450 68.5 450 — — 3 7.8
53.5 305 53.5 305 — — 3 4.8 39.5 260 39.5 260 — — 3 4.8
44.2 270 44.2 270 — — 3 4.0 32.6 215 32.6 215 — — 3 4.0
35.4 210 35.4 210 — — 3 3.1 26.1 180 26.1 180 — — 3 3.1
100.2 550 100.2 550 — — 3 8.2 100.2 550 100.2 550 — — 3 8.2
92.8 550 92.8 550 — — 3 7.8 92.8 550 92.8 550 — — 3 7.8
53.5 305 53.5 305 — — 3 4.8 53.5 305 53.5 305 — — 3 4.8
44.2 270 44.2 270 — — 3 4.0 44.2 270 44.2 270 — — 3 4.0
35.4 210 35.4 210 — — 3 3.1 35.4 210 35.4 210 — — 3 3.1
73.9 450 73.9 450 73.9 450 3 8.2 100.2 550 100.2 550 — — 3 8.2
68.5 450 68.5 450 68.5 450 3 7.8 92.8 550 92.8 550 — — 3 7.8
39.5 260 39.5 260 39.5 260 3 4.8 53.5 305 53.5 305 — — 3 4.8
32.6 215 32.6 215 32.6 215 3 4.0 44.2 270 44.2 270 — — 3 4.0
26.1 180 26.1 180 26.1 180 3 3.1 35.4 210 35.4 210 — — 3 3.1
73.9 450 73.9 450 73.9 450 4 8.2 73.9 450 73.9 450 73.9 450 4 8.2
68.5 450 68.5 450 68.5 450 4 7.8 68.5 450 68.5 450 68.5 450 4 7.8
39.5 260 39.5 260 39.5 260 4 4.8 39.5 260 39.5 260 39.5 260 4 4.8
32.6 215 32.6 215 32.6 215 4 4.0 32.6 215 32.6 215 32.6 215 4 4.0
26.1 180 26.1 180 26.1 180 4 3.1 26.1 180 26.1 180 26.1 180 4 3.1
100.2 550 100.2 550 100.2 550 4 8.2 73.9 450 73.9 450 73.9 450 4 8.2
92.8 550 92.8 550 92.8 550 4 7.8 68.5 450 68.5 450 68.5 450 4 7.8
53.5 305 53.5 305 53.5 305 4 4.8 39.5 260 39.5 260 39.5 260 4 4.8
44.2 270 44.2 270 44.2 270
4 4.0 32.6 215 32.6 215 32.6 215 4 4.0
35.4 210 35.4 210 35.4 210 4 3.1 26.1 180 26.1 180 26.1 180 4 3.1
"Replacement
information at
back of manual"
