Johnson Controls York YCAL0124E Series User Manual

JOHNSON CONTROLS
28
FORM 150.62-NM6 (103)
Installation
See Notes and Legend on page 19.
One Field Provided Power Supply Circuit to the chiller. Field connections to Factory Provided Terminal Block (optional) or Non-Fused Discon-
nect Switch (optional). Includes Individual Branch Circuit Protection (Breakers) per electrical system
ELECTRICAL DATA – SINGLE POINT POWER SUPPLY CONNECTIONS WITH INDIVIDUAL SYSTEM
CIRCUIT BREAKERS – YCAL0090E_ - YCAL0124E_
TABLE 6 – SINGLE POINT POWER SUPPLY CONNECTIONS WITH INDIVIDUAL SYSTEM
CIRCUIT BREAKERS
MODEL YCAL VOLT HZ
SINGLE POINT FIELD SUPPLIED WIRING
MCA
1
MIN N/F
DISC SW
2
D.E. FUSE CKT. BKR.
5
INCOMING (LUGS) WIRE RANGE
6
TERMINAL BLOCK (opt) NF DISC. SWITCH (opt)
MIN
3
MAX
4
MIN MAX
0090
200 60 423 600 450 500 450 500 (2) # 4 - 500 (1 or 2) 3/0 - 500
230 60 393 600 450 450 450 450 (2) # 4 - 500 (1 or 2) 3/0 - 500
380 60 229 250 250 250 250 250 (2) # 4 - 500 (1) # 6 - 350
460 60 188 250 250 200 250 200 # 6 - 400 (1) # 6 - 350
575 60 151 200 200 175 200 175 # 14 - 2/0 (1) # 6 - 350
0094
200 60 476 600 600 600 600 600 (2) # 4 - 500 (1 or 2) 3/0 - 500
230 60 442 600 500 500 500 500 (2) # 4 - 500 (1 or 2) 3/0 - 500
380 60 257 400 300 300 300 300 (2) # 4 - 500 (1 or 2) 3/0 - 500
460 60 211 250 225 250 225 250 # 6 - 400 (1) # 6 - 350
575 60 169 200 200 200 200 200 # 6 - 400 (1) # 6 - 350
0104
200 60 513 600 600 600 600 600 (2) # 4 - 500 (1 or 2) 3/0 - 500
230 60 477 600 500 500 500 500 (2) # 4 - 500 (1 or 2) 3/0 - 500
380 60 278 400 300 300 300 300 (2) # 4 - 500 (1 or 2) 3/0 - 500
460 60 228 250 250 250 250 250 # 6 - 400 (1) # 6 - 350
575 60 183 200 200 200 200 200 # 6 - 400 (1) # 6 - 350
0114
200 60 528 600 600 600 600 600 (2) # 4 - 500 (1 or 2) 3/0 - 500
230 60 491 600 600 600 600 600 (2) # 4 - 500 (1 or 2) 3/0 - 500
380 60 286 400 300 300 300 300 (2) # 4 - 500 (1 or 2) 3/0 - 500
460 60 235 400 250 250 250 250 # 6 - 400 (1 or 2) 3/0 - 500
575 60 188 250 200 200 200 200 # 6 - 400 (1) # 6 - 350
0124
200 60 607 800 700 700 700 700 (2) # 4 - 500 (1 or 2) 3/0 - 500
230 60 564 800 600 600 600 600 (2) # 4 - 500 (1 or 2) 3/0 - 500
380 60 328 400 350 350 350 350 (2) # 4 - 500 (1 or 2) 3/0 - 500
460 60 269 400 300 300 300 300 # 6 - 400 (1 or 2) 3/0 - 500
575 60 216 250 250 250 250 250 # 6 - 400 (1) # 6 - 350
"Replacement
information at
back of manual"
