ELECTRICAL DATA
1
TABLE 2 – SINGLE-POINT POWER SUPPLY
See Notes and Legend on page 19
SINGLE-POINT POWER SUPPLY CONNECTIONS – YCAL0014E_ - YCAL0034E_
(One Field Provided Power Supply to the chiller. Field connections to Factory Provided Power Terminal Block (standard), Non-Fused Discon-
nect Switch (optional) or Circuit Breaker (optional).)
MODEL
YCAL
VOLT HZ
SINGLE POINT FIELD SUPPLIED WIRING SYSTEM #1 COMPRESSOR & FAN
MCA
1
MIN
N/F
DISC
SW
2
D.E. FUSE
CKT.
BKR.
5
INCOMING (LUGS) WIRE RANGE
6
COMPR. #1 COMPR. #2
COMPR.
#3 FANS
TERMINAL
BLOCK
(std)
NF DISC.
SWITCH
(opt)
CIRCUIT
BREAKER
(opt)MIN
3
MAX
4
MIN MAX RLA LRA RLA LRA RLA LRA QTY FLA(EA)
0014 200 60 71 100 80 90 80 90 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 24.0 189 24.0 189 — — 2 8.2
230 60 70 100 80 90 80 90 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 24.0 189 24.0 189 — — 2 7.8
380 60 42 60 50 50 50 50 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 14.4 112 14.4 112 — — 2 4.8
460 60 35 60 40 45 40 45 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 12.0 99 12.0 99 — — 2 4.0
575 60 28 30 35 35 35 35 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 9.6 74 9.6 74 — — 2 3.1
0020 200 60 92 100 100 110 100 110 # 10 - # 1 # 10 - 1/0 # 3 - 3/0 33.2 278 33.2 278 — — 2 8.2
230 60 91 100 100 110 100 110 # 10 - # 1 # 10 - 1/0 # 3 - 3/0 33.2 278 33.2 278 — — 2 7.8
380 60 55 60 60 70 60 70 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 19.9 151 19.9 151 — — 2 4.8
460 60 46 60 50 60 50 60 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 16.6 127 16.6 127 — — 2 4.0
575 60 37 60 40 45 40 45 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 13.3 100 13.3 100 — — 2 3.1
0024 200 60 107 150 125 125 125 125 # 10 - # 1 # 3 - 3/0 # 3 - 3/0 40.0 350 40.0 350 — — 2 8.2
230 60 106 150 125 125 125 125 # 10 - # 1 # 3 - 3/0 # 3 - 3/0 40.0 350 40.0 350 — — 2 7.8
380 60 64 100 70 80 70 80 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 24.0 195 24.0 195 — — 2 4.8
460 60 53 60 60 70 60 70 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 19.9 167 19.9 167 — — 2 4.0
575 60 43 60 50 50 50 50 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 16.0 125 16.0 125 — — 2 3.1
0030 200 60 124 150 150 150 150 150 # 10 - 3/0 # 6 - 350 # 6 - 350 47.8 425 47.8 425 — — 2 8.2
230 60 124 150 150 150 150 150 # 10 - 3/0 # 6 - 350 # 6 - 350 47.8 425 47.8 425 — — 2 7.8
380 60 75 100 90 90 90 90 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 28.7 239 28.7 239 — —- 2 4.8
460 60 62 100 70 70 70
70 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 23.9 198 23.9 198 — — 2 4.0
575 60 50 60 60 60 60 60 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 19.1 148 19.1 148 — — 2 3.1
0034 200 60 147 200 175 175 175 175 # 10 - 3/0 # 6 - 350 # 6 - 350 40.0 350 40.0 350 40.0 350 2 8.2
230 60 146 200 175 175 175 175 # 10 - 3/0 # 6 - 350 # 6 - 350 40.0 350 40.0 350 40.0 350 2 7.8
380 60 88 100 100 110 100 110 # 10 - # 1
# 10 - 1/0 # 3 - 3/0 24.0 195 24.0 195 24.0 195 2 4.8
460 60 73 100 80 90 80 90 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 19.9 167 19.9 167 19.9 167 2 4.0
575 60 59 100 70 70 70 70 # 10 - # 1 # 10 - 1/0 # 10 - 1/0 16.0 125 16.0 125 16.0 125 2 3.1
"Replacement
information at
back of manual"
