YORK INTERNATIONAL
18
FORM 150.62-NM6 (LS1)
DIMENSIONS - YCAL0114 - YCAL0134 (ENGLISH)
Z
Y
20"
G
C
7 7/8"
91 7/16"
A
29"
D
A
G
C
ORIGIN
21 1/8"
88 1/4"
19 1/8"
RIGGING HOLES
190"
X
183"
67 1/4"
(EACH SIDE)
WATER OUTLET
83"
8"
WATER INLET
8"
VIEW D-D
X
59"
(4) 3" X 3"
1 1/4
MOUNTING
POWER PANEL
POWER PANEL
CONTROL PANEL
CONTROL PANEL
HOLES (TYP.)
3/4" DIA.
1 1/4
96"
D
67 1/4"
7 7/8"
50" *
38"
22 3/4"
59"
A
BC D
E
FG
H
* 63" for -17 and -28
voltage panels
ALUMINUM
COPPER
YCAL
Center of Gravity (in.)
XYZ
0114 82.2 45.5 43.7
0124 81.1 46.2 43.1
0134 81.9 46.8 42.5
YCAL
Center of Gravity (in.)
XYZ
0114 83.3 45.2 45.3
0124 82.3 45.9 44.7
0134 82.9 46.5 44.2
LD08705
